M45 SHORTGUN
AIMABLE CEILING MIC
INSTALLATION &
OPERATING GUIDE
The Audix Dante–AES67 microphone systems are the industry’s first integrated
solution to eliminate multiple connectors by providing audio, LED status and logic
functionality with a single RJ45 cable connection. This design reduces conventional
wiring and installation time by 90% and eliminates wiring errors. Once the connection
is made to the network via the Audix DN4 interface, the Audix microphone(s) will be
automatically recognized and populated by model number in the Audix DSP plugin.
IN THE BOX
• M45WD microphone
• Knurled fastener
• Seismic / restraint cable
• Spec sheet
• Installation guide
THE AUDIX INTEGRATED MICROPHONE SYSTEM | DANTE–AES67
SWITCH
DSP
AUDIX DN4
FIGURE 6
Connect the DN4 Dante interface to a
PoE switch (see DN4 guide).
FIGURE 1
Determine the microphone placement,
drill a 1.5 inch (38mm) hole in the ceiling
tile or mounting surface.
FIGURE 3
For seismic cable installation, wrap the
cable through beam, eyebolt or hanger
and cable stay barrel (see figure 4).
Remove M45 placement screw and place
eyelet over hole and tighten screw.
FIGURE 2
Remove the knurled ring from the
module, insert the module through
the hole and reattach the knurled ring.
Connect RJ45 cable to the M45 module.
FIGURE 4
Cable Stay Operation
FIGURE 5
Connect up to 4 microphones via Cat5 -
7 to the Audix DN4 interface.
INSTALLATION
CABLE RELEASE PIN
CABLE STAY
BARREL
CABLE
Product Specifications
| Brand: | Audix |
| Category: | Microphone |
| Model: | M45 Shortgun |
