Package Contents:
(1) CM012 - Friction style dashboard mount
(1) GN014-SBH - Suction pedestal with swivel ball head
(1) Optional adhesive safety hook (recommended but not required)
(1) Alcohol cleaning pad
CM012 with GN014-SBH
Friction Dashboard Mount
with Pedestal
CM012-2
| Friction Dashboard Mount with Travelmount™ Mini Suction Pedestal
!Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists
Consumer Hotline:
USA (800) 841-0884
INTL (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
Dashboard Mount Installation
Find a safe location on the vehicle dashboard that is not in
an airbag deployment zone.
Optional Safety hook installation will add extra stability.
Clean the desired area with the included alcohol pad and
let dry. Remove the adhesive backing on the safety anchor.
The hook on the anchor must point towards the windshield.
Press and hold the hook down on to the dashboard surface
for about a minute. Allow 24 hrs. to cure to the dashboard
surface at room temperature (72° F.)
Place the loop on the back of the dashboard mount around
the safety hook and place on the dashboard in front of the
hook.
Remove protective fi lm from pedestal mounting surface
(A). Lower the pedestal onto the disc and press down
rmly. Flip the locking lever down to secure the pedestal to
the dash mount.
Continued on other side...
Step 1.
Step 2.
Step 3.
Step 4.
A
W
I
N
D
S
H
I
E
L
D
Hook towards windshield
Patent Pending
Do not place mount in or near an air bag deployment zone
or where it will obstruct view of the road.
!
Device Compatibility:
- For use with any dual T-slot device or adapter plate.
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2010 Arkon Resources, Inc.
CM012-2
| Friction Dashboard Mount with Travelmount™ Mini Suction Pedestal
!Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists
Consumer Hotline:
USA (800) 841-0884
INTL (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
Dashboard Mount Installation - Continued
Adjust the angle of the pedestal arm by tightening the
rotation knob.
Adjust the angle of the pedestal head by tightening the
head adjustment knob.
Step 5.
Step 6.
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2010 Arkon Resources, Inc.
Angle Knob
Angle Knob
Angle Knob
Angle Knob
Angle Knob
