Page 1/39
Installation / User Manual
Rev 3.0
© All Rights Reserved
APsystems ECU-C Energy communication unit
with advanced functions
ECU-C Installation/User Manual
1
Table of Contents
Important Safety Instructions...................................................................................
2
1.Introduction............................................................................................................
3
2.Interface Explanation.............................................................................................
4
Interface Layout............................................................................................................... 4
2.1 AC Input Port..............................................................................................................5
2.2 DC Input Port..............................................................................................................5
2.3 RJ45 Ethernet Network Port...................................................................................... 5
2.4 RJ45 Signal Only for Australia( )............................................................................. 5
2.5 AP............................................................................................................................... 6
2.6 Power......................................................................................................................... 6
2.7 USB Interface............................................................................................................. 6
2.8 Reset.......................................................................................................................... 6
2.9 LED............................................................................................................................. 6
3.Hardware Installation.............................................................................................
7
3.1 Preparation................................................................................................................ 7
3.2 Selecting an Installation Location for the ECU-C........................................................7
3.3 Cable Connections..................................................................................................... 9
3.4 RJ45 Signal connection.............................................................................................. 9
3.5 Internet Connection...................................................................................................9
3.6 Current transformer interface................................................................................. 11
3.7 Contactor connection.............................................................................................. 12
4.Basic Operation....................................................................................................
13
4.1 Restore the factory set operation............................................................................ 13
5. ECUAPP................................................................................................................
14
5.1 Connecting to the ECU-C via the Local Wireless......................................................14
5.2 Add UID.................................................................................................................... 15
5.3 Delete UID................................................................................................................15
5.4 Homepage................................................................................................................15
5.5 Data.......................................................................................................................... 16
5.6 Settings.....................................................................................................................18
5.7 EMA Registration function.......................................................................................23
6.Local Network Interface.......................................................................................
25
6.1 Connecting to the ECU-C via the Local Wireless......................................................25
6.2 Home Screen............................................................................................................25
6.3 Real-time Data Screen..............................................................................................27
6.4 Administration Screen..............................................................................................27
6.5 Advanced Screen......................................................................................................30
7.Remote ECU-C Management (EMA)....................................................................
32
7.1 ECU-C Configuration/ECU-C Status Page................................................................. 33
7.2 Setting the ECU-C Time Zone................................................................................... 34
7.3 Managing Inverter IDs and Updating the Inverter ID List........................................34
8.Technical Data......................................................................................................
36
ECU-C Installation/User Manual
2
Important Safety Instructions
Symbols replace words on the equipment, on a display, or in
manuals
Trademark.
Caution, risk of electric shock.
Equipment protected throughout by double insulation or
reinforced insulation
CE mark is attached to the solar inverter to verify that the unit
follows the provisions of the European Low Voltage and EMC
Directives.
Qualified
personnel
Person adequately advised or supervised by an electrically
skilled person to enable him or her to perceive risks and to avoid
hazards which electricity can create. For the purpose of the
safety information of this manual, a "qualified person" is
someone who is familiar with requirements for safety,
refrigeration system and EMC and is authorized to energize,
ground, and tag equipment, systems, and circuits in accordance
with established safety procedures. The inverter and endues
system may only be commissioned and operated by qualified
personnel.
