Page 1/26
Discreet
Acoustics
Modular PLUS
Series
2 Discreet Acoustics Modular PLUS Series
Table of Contents
ξ˜ƒ ξ˜ƒ
Safety .......................................................................................................................... 3ξ˜ƒ
Environment ................................................................................................................ 3ξ˜ƒ
ξ˜ƒ ξ˜ƒ
Introduction ................................................................................................................. 4ξ˜ƒ
ξ˜ƒ ξ˜ƒ
ξ˜ƒ ξ˜ƒ
Capsule Modules ......................................................................................................... 6ξ˜ƒ
ξ˜ƒ ξ˜ƒ
CK49 .......................................................................................................................... 7ξ˜ƒ
CK43 .......................................................................................................................... 8ξ˜ƒ
CK41 .......................................................................................................................... 9ξ˜ƒ
GN15,30,50 M .......................................................................................................... 10ξ˜ƒ
GN155 M .................................................................................................................. 11ξ˜ƒ
HM1000 M ................................................................................................................ 12ξ˜ƒ
PAESP M ................................................................................................................... 13ξ˜ƒ
PAE5 M ..................................................................................................................... 14ξ˜ƒ
PAE M ....................................................................................................................... 15ξ˜ƒ
ξ˜ƒ ξ˜ƒ
Mounting Material ...................................................................................................... 16ξ˜ƒ
MF M .................................................................................................................. 16ξ˜ƒ
H600 ................................................................................................................... 16ξ˜ƒ
H500 ................................................................................................................... 17ξ˜ƒ
ST45 (+SA60) ...................................................................................................... 17ξ˜ƒ
SA60 ................................................................................................................... 17ξ˜ƒ
Cables ....................................................................................................................... 18ξ˜ƒ
MK150 M ............................................................................................................ 18ξ˜ƒ
MK150 ML .......................................................................................................... 18ξ˜ƒ
Accessories ............................................................................................................... 18ξ˜ƒ
UWA9 M .............................................................................................................. 18ξ˜ƒ
W40 M ................................................................................................................ 18ξ˜ƒ
ξ˜ƒ ξ˜ƒ
ξ˜ƒ ξ˜ƒ
ξ˜ƒ ξ˜ƒ
ξ˜ƒ ξ˜ƒ
Table of Contents
Discreet Acoustics Modular PLUS Series 3
Safety and Environment
ο‚· Do not expose the equipment to direct sunlight, excessive dust, moisture, rain, mechanical
vibrations, or shock.
ο‚· Do not spill any liquids on the equipment or allow objects to fall inside through the
ventilation slots.
ο‚· The equipment must only be used in dry rooms.
ο‚· The equipment must only be opened, serviced, and repaired by authorised personnel. The
equipment contains no user-serviceable parts.
ο‚· If any solid object or liquid should get into the equipment, shut down the system
immediately.
ο‚· Do not place the equipment near heat sources such as radiators, heating ducts, amplifiers,
etc. and do not expose it to direct sunlight, excessive dust, moisture, rain, mechanical
vibrations, or shock.
ο‚· To avoid hum or interference, route all audio lines, particularly those connected to the
microphone inputs, away from power lines of any type. If you use cable ducts, be sure to
use separate ducts for the audio lines.
ο‚· Clean the equipment with a moistened (not wet) cloth only. Be sure to disconnect the AC
adapter from the power outlet before cleaning the equipment. Never use caustic or
scouring cleaners or cleaning products containing alcohol or solvents since these may
damage the enamel and plastic parts.
ο‚· Only use the equipment for the applications described in this manual. AKG cannot accept
any liability for damages resulting from improper handling or misuse.
ο‚· Electrostatic charges may damage electronic circuits. Therefore, be sure to touch a bare,
grounded metal part to discharge any static charge that may have built up on your body,
before touching any electronic circuit board.
ο‚· The packaging of the equipment is recyclable. To dispose of the packaging, make sure to
use a collection/recycling system provided for that purpose and observe local legislation
relating to waste disposal and recycling.
1 Safety and Environment
Safety
Environment
