CHORUSAURUS®
Combining analog -bucket brigade technology with the precision and
flexibility of rn circuits, the Chorusaurus mode ® produces lush, organic
chorusing effects that won’t compromise your low end. Using intuitive
and flexible controls, bassists can dial in that perfect chorus effect.
Features:
• Uses analog bucket-brigade technology
• Independent adjustment of all chorus effect parameters
• Stereo or Mono output
• Gig-saver bypass (signal passes even if your battery dies)
• Heavy duty steel construction
• Three- year limited warranty
• Power: 9 volt battery or optional power supply
Owner’s Manual
Manual Version 1.1
I. Functions
A. Top Panel:
BLEND: Controls the mix ratio between clean and modulated signal.
The most dramatic chorusing effect is achieved when the knob is set to the 12:00
position (50:50 ratio).
When this knob is fully counterclockwise t ratio is 90he mix : 10 in favor of clean
signal. When this knob is fully clockwise the mix ratio is reversed and favors the
modulated signal 10:90.
RATE: Controls the speed of modulation.
INTENSITY: Controls the intensity of the modulation. Higher intensity produces
more dramatic chorusing effect.
WIDTH: Sets the range for the INTENSITY to work within. Turning WIDTH
clockwise will broaden the range allowing more intense effect. ,
ENGAGE: Toggles between on and off. The blue LED indicates that the effect is on.
B. Side Panel:
IN: ¼” input
DC IN: This is a standard 2.1mm DC jack. The center terminal polarity is negative.
OUT: ¼” output
• For mono output use a standard ¼” cable to your amplifier.
• For stereo operation with two amplifiers use a ¼” Y adapter cable
with one ¼” TRS plug to two ¼” TS jacks.
C. Specifications:
Current consumption:………………………..12mA
Input impedance: ............................................1MΩ (Effect On)
Output impedance: .........................................1 KΩ
External DC Power: 10VDC, center terminal negative -………………………..9
II. Sample Settings
Please visit our website, www.aguilaramp.com, for sample settings.
III. How to change the battery
This operation can be done quickly and easily with a standard #2 Philips screw
d river!
The battery is easily accessible by loosening the screw on the bottom of the unit. The
battery compartment will slide forward and you will be able to see the padded area
to insert the battery and attach the battery clips. Once the battery has been replaced,
simply slide the compartment back in and tighten the screw.
