Page 1/72
ZM-VE500
English
Quick Guide
- Please download the latest firmware and each language quick guide.
from www.zalman.com.
Ver. 151130
www.ZALMAN.com
2WWW.ZALMAN.COM
1. Information
Be sure to always back up important data
Do not arbitrarily disassemble.
Caution: Electrostatic
2. Components (Components may be changed without notice.)
■ This manual is for handling and using ZM-VE500.
■ Please read “Caution” before using the device.
■ Please check “Troubleshooting” when issue occurs.
■ The external HDD manufacturer is not responsible for any data stored in the
external HDD not liable for any emotional or physical damages caused due to data
loss.
■ If you disassemble the product or remove/damage the stickers and/or labels
attached on the product, you cannot receive the warranty service.
■ Do NOT touch the circuit with bare hands. The chip controlling the ZM-VE500's
virtual CD-ROM is a electrostatic sensitive part. ZM-VE500 may not operate properly if
the circuit is damaged by the electrostatic discharge.
※ Visit official homepage (www.zalman.com) to download firmware upgrades and
ZM-VE500 User Guide.
※ This User Guide is subject to change without prior notice to users in order to
enhance the product features and to apply the firmware upgrade.
Quick Guide
ZM-VE500 Pouch Screw Driver & Bolts 2pcs
USB 3.0 Cable
Quick Guide
1
Reminder
3
WWW.ZALMAN.COM
3. Name of Parts
4. Specification (It may be changed without notice.)
5. System Minimum Requirement
No. Part Name
①USB 3.0 Port :USB 3.0 Cable Port
②LED Indicator: Read / Write LED lighting
(Blue LED: USB3.0, White LED: USB2.0)
③LCD Display Panel: File list and Menu
④Touch Panel: Select file and Control menu
⑤Enter : "Enter" and "Select"
⑥Menu : Enter/ Exit “Menu mode ”
⑦5 : Mount / Unmount Virtual ODD
⑧Update ISO file list (after copying iso file)
■ Intel Pentium / 350MHz or higher CPU
■ Memory 60MB or higher
■ System should have USB CD booting bios
(Most of PC manufactured before 2003 doesn’t support CD-ROM booting)
Model
Spec. ZM-VE500
Case Material Aluminum alloy, Acryl, Poly carbonates (PC)
Weight 91g (except Hard disk)
Dimensions 146 x 80.8 x 14 (L x W x H / mm)
Interface USB 3.0/2.0/1.1 SATA Ⅰ
/Ⅱ/Ⅲ
Maximum Transfer Rate
5Gbps
Power
DC5V(USB Power), 2.5" Hard disk
Support OS
Window XP / Linux 2.6 / MAC OS X 1.0.0 or higher
