Page 1/4
① One (1) NC1500
③ One (1) User’s Manual② One (1) USB Power Cable
1
1.Safety Precautions
2. Specifications
3. Components
pure AL, ABS, nylon, rubber synthetic, silicon
789g
345(L) X 299(W) X 52(H)mm
18.0dBA ~ 23.5dBA ±10%
5V(USB powered)
Centrifugal Fan
2 units
FDB(Fluide Dynamic Bearing)
1,100RPM ~ 1,500RPM ±10%
Materials
Weight
Dimensions
Noise Level(dBA)
Input Voltage
Type
Units
Bearing-type
RPM
Fan
Disclaimer) Zalman Tech Co., Ltd. is not responsible for any damages due to external causes,
including but not limited to, improper use, problems with electrical power, accident,
neglect, alteration, repair, improper installation, or improper testing.
1) Check the components list and condition of the product before use. If any problem is found,
contact the retailer to obtain a replacement.
2) Zalman Tech Co., Ltd. is not responsible for any damages due to improper product use.
3) Excessive force exerted on the product may cause critical damage to the product and/or
system.
4) To prevent damages, do not allow objects to obstruct fan rotation.
5) To prevent shorting and/or damage of the fans, do not spill liquids on the unit.
6) Do not obstruct the air inlets.
7) Use on a flat and vibration-free surface.
8) Do not use in humid or dusty, under direct sunlight, or other heat sources.
9) Please seal the unit airtight when storing for prolonged periods to prevent buildup in the
inlets.
10) Product designs and specifications may be revised without prior notification to improve
quality and performance.
2
4. Features
5. Usage
Activity LED
RPM Dial
On/Off Switch
USB Power Cable
USB Device
USB Ports
When using the NC1500 USB port for power and data transfer, use devices that draw
no more than 1.9W.
Caution
Cooling performance improves proportionally with the gap between the notebook and
the cooler.
1) To power the unit, connect the NC1500 and Notebook Computer using the included
USB Power Cable.
2) Turn the Notebook Cooler’s On/Off Switch “On”.
3) Adjust the RPM Dial to the preferred noise and performance setting.
※One (1) USB device can be connected to the NC-1500’s USB port.
