Xvive LV1 is a miniature professional lavalier microphone for use with the Xvive U5

Wireless Audio for Video System, or other broadcast/recording devices. This small

omni-directional clip-on microphone includes a locking 3.5mm connector, and

easily attaches to any clothing. It’s designed for speech and vocal applications and

features high-level speech intelligibility.

FEATURES

• Superior audio clarity

• Natural response across the frequency range

• Low distortion

• Includes both a foam windscreen and a fur windshield for

attenuating breath noise and wind noise

• Matte black, sleek, low-prole design

• Microphone capsule with omni-directional pickup pattern

• The plug locks and is compatible with standard TRS interface

Microphone Connector

Mono 3.5mm TRS output. Ensure the

connected device provides a regulated +

2.5V to 10V voltage to the “+” conductor.

LV1 LAVALIER MICROPHONE

Microphone

Dimensions

Weight

Directivity

Sensitivity

Frequency response

Impedance

Signal-to-noise ratio

Current consumption

Operating voltage

Maximum input Sound Pressure Level

Electret condenser microphone

ϕ 8 × 19 mm (cable: 1.6 m / 5.25 ft)

13 g /0.46 oz

Omni-directional

-32 dB ± 3 dB

30 Hz – 20 kHz

2.5 kΩ ± 30%

75 dB

400μA Max

3.3V (2.5V to 10V)

120 dB SPL

P R O F E S S I O N A L W E A R A B L E M I R O P H O N E

LAVALIER MICROPHONE

TRS Wiring Diagram

“+” Audio output

and bias voltage

Ground

LAVALIER MICROPHONE SETUP

a) Install windscreen and mic clip on the lavalier

microphone (see “INSTALL CLIP” diagrams);

b) Use the mic clip to attach the microphone to

clothing, as desired;

c) Run the mic cable to the transmitter in a way that

avoids friction noise, and so that the cable and

the wireless transmitter antenna do not cross;

d) The Xvive LV1 Lavalier Microphone has an

omni-directional pickup pattern. Keep at least

10 inches away from your mouth or audio source.

Plug the 3.5mm TRS lavalier microphone plug into

your recording device or wireless audio transmitter.

QUICK STARTINSTALL CLIP

SHENZHEN FZONE TECHNOLOGY CO., LTD.

2nd ﬂoor, Building 12, Xicheng Industrial Area, Xixiang

Town, Baoan District, Shenzhen Guangdong, China.

www.xviveaudio.com

Made in China

>10 inches
