WITHINGS
PR OD U CT GUIDE
This guide explains how to use your Withings Body Scan, and gives
additional regulatory information on how to use the Withings ECG
Monitor on your Withings Body Scan. It applies to users in Europe,
United Kingdom, Switzerland, Australia, New Zealand and Hong Kong.
EN – NON-US REGIONS
USER GUIDE
Important notice
Before using Withings Body Scan, review the information
in this guide. You may also find this guide online at:
https://www.withings.com/guides
For more information on how to use the Withings ECG
Monitor with your Withings Body Scan, please refer to
the Withings ECG Monitor Instructions for Use, available
at: https://www.withings.com/guides
Retain this documentation for future reference.
Installation instructions are available within the Quick
Start Guide provided with this user guide. Please contact
Withings when in need of assistance, setting up, using or
maintaining the device or to report unexpected operations
or events. Any serious incident that has occurred in relation
to the Withings Body Scan should be reported to Withings
and competent authorities in your country of residence.
Disclaimer
Information in this guide may change without notice.
WITHINGS,
2 rue Maurice Hartmann,
92130 Issy-les-Moulineaux,
FRANCE 1282
Intended Use (Non-US Regions)
Contraindications
Withings Body Scan is a connected smart scale providing
the following features without medical purposes:
- measure weight
- calculate Body Mass Index (BMI)
- measure body composition
- measure pulse rate
- measure pulse wave velocity
- estimate vascular age
Additionally, Withings Body Scan is intended to detect and follow-up
peripheral autonomic neuropathies in an adult population
by performing measurements on the feet, on intact skin or in the
presence of damaged skin, such as, but not limited to, blisters,
callosities or wounds.
Withings Body Scan comprises electrodes intended to acquire
an ECG signal used by Withings ECG Monitor.
Do not use the Withings Body Scan if you have a cardiac pacemaker,
an implantable cardioverter-defibrillator (ICD), or other implanted
electronic devices.
Warnings & safety notice
EN
FR
4
How to use Withings Body Scan
and take a first measurement
How Withings Body Scan obtains a Nerve Health Score
- The Nerve Health Score is based on a Galvanic Skin Response
measurement which consists of a chronoamperometric
measurement of the feet. It provides an accurate evaluation
of sweat gland function, also called sudomotor function.
- Withings Body Scan measures the ability of the sweat glands
to release chloride ions in response to an electrical stimulus on
the soles of the feet, the area with the highest sweat gland density.
- The measurement focuses on small nerve fibers that stimulate
the sweat glands. The degeneration of these small nerve fibers
reduces sweat gland stimulation and impairs the sudomotor
function.
What is a Nerve Health Score?
Taking a Nerve Health Score
Measurement
How to obtain a Nerve Health Score
- Make sure the Withings Body Scan is on a stable floor, and
that you have activated and enabled a Nerve Health Score
measurement in the Withings application.
- Optional: grab the handle. Please note that the measurement
does not require holding the handle. A Nerve Health Score
measurement can be performed even if the handle is in
its storage position.
- Step on the scale with bare feet. Make sure your feet are clean
and well positioned on the electrodes. See images below to
ensure your feet are well positioned.
- Withings Body Scan will deliver a final Nerve Health Score
reading at the end of each month. The reading might be
inconclusive if we were not able to accurately assess your
score. We might invite you to take a Guided Scan measurement
in specific conditions in order to get a result. To get the most
accurate measurements always take the Nerve Health Score
measurements in the conditions described in the Guided Scan.
- Follow the information in the Quick Start Guide and in the
Withings application to set-up your device.
- To wake up your device for the first time, please press the power
button for 3 seconds. If your product is not starting, consider
charging it for a minimum of three hours and try again.
- Once your product is installed and configured, it will appear
in your devices list in settings.
- You may have to follow some tutorials in the Withings application
in order to activate some measurements. Withings ECG Monitor
requires you to follow a tutorial for the activation of the metric.
- To take the first measurement, grab the handle (optional)
and step on the scale with bare feet. Your name, or trigram
(as configured in the app), will appear on the scale’s screen
at the end of the weight measurement: it means your scale
has correctly identified you and the measurements sequence
(as defined in the app) will follow.
- If it is not the case, the measurement will most likely appear
in “Unknown Measurements” in the application. Please assign
it to your user so that the scale can automatically recognize
the user during the next weigh-in.
Nerve Health Score Outputs
