Whirlpool AKZ9S 8220 IX Manual
Read below 📖 the manual in Italian for Whirlpool AKZ9S 8220 IX (39 pages) in the Oven category. This guide has been helpful for 13 people and has been rated 4.5 stars on average by 2 users
Page 1/39
EN
Owner’s Manual
THANK YOU FOR BUYING A
WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register PLEASE SCAN THE QR CODE ON
YOUR APPLIANCE IN ORDER TO
REACH MORE INFORMATION
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
5
4
3
2
1
5
4
3
2
1
1
2
3
48
9
10
5
7
6
1. Control panel
2. Fan
3. Circular heating element
(not visible)
4. Shelf guides
(the level is indicated on the
front of the oven)
5. Door
6. Water drawer
7. Upper heating element/grill
8. Lamp
9. Identification plate
(do not remove)
10. Lower heating element
(not visible)
CONTROL PANEL DESCRIPTION
1 2 34 5 76 8 9
1. ON / OFF
For switching the oven on and
off and for stopping an active
function.
2. FUNCTIONS DIREC T ACCESS
For quick access to the functions
and menu.
3. NAVIGATION BUTTON MINUS
For scrolling through a menu and
decreasing the settings or values
of a function.
4. BACK
For returning to the previous
screen.
During cooking, allows settings to
be changed.
5. DISPLAY
For immediately starting a
function.
6. CONFIRM
For confirming a selected function
or a set value.
7. NAVIGATION BUTTON PLUS
For scrolling through a menu and
increasing the settings or values of
a function.
8. OPTIONS / FUNCTIONS DIRECT
ACCESS
For quick access to the functions,
duration, settings and favorites.
9. START
For starting a function using the
specified or basic settings.
ACCESSORIES
WIRE SHELF DRIP TRAY BAKING TRAY SLIDING RUNNERS*
Use to cook food or as a
support for pans, cake tins
and other ovenproof items
of cookware.
Use as an oven tray for
cooking meat, sh,
vegetables, focaccia, etc. or
position underneath the wire
shelf to collect cooking
juices.
Use for cooking all bread and
pastry products, but also for
roasts, sh en papillotte, etc.
To facilitate inserting or
removing accessories.
AIR FRY TRAY *
To be used when cooking
foods with Air Fry function,
with a baking tray positioned
at a lower level to collect
possible crumbs and drip.
It can be cleaned in the
dishwasher.
* Available only on certain models
The number and the type of accessories may vary depending on which model is purchased.
Other accessories can be purchased separately; for orders and information contact the after sales service or
www . whirlpool . eu.
INSERTING THE WIRE SHELF AND OTHER
ACCESSORIES
Insert the wire shelf horizontally by sliding it across
the shelf guides, making sure that the side with the
raised edge is facing upwards.
Other accessories, such as the drip tray and the
baking tray, are inserted horizontally in the same way
as the wire shelf.
REMOVING AND REFITTING THE SHELF GUIDES
• To remove the shelf guides, lift the guides up and
then gently pull the lower part out of its seating:
The shelf guides can now be removed.
• To refit the shelf guides, first fit them back into
their upper seating. Keeping them held up, slide
them into the cooking compartment, then lower
them into position in the lower seating.
FITTING THE SLIDING RUNNERS (IF PRESENT)
Remove the shelf guides from the oven and remove
the protective plastic from the sliding runners.
Fasten the upper clip of the runner to the shelf guide
and slide it along as far as it will go. Lower the other
clip into position. To secure the guide, press the lower
portion of the clip firmly against the shelf guide.
Make sure that the runners can move freely. Repeat
these steps on the other shelf guide on the same
level.
Please note: The sliding runners can be tted on any level.
FUNCTIONS
6th SENSE
These allow a fully automatic cooking for all
types of food (Lasagna, Meat, Fish, Vegetables, Cakes
& Pastries, Salty cakes, Bread, Pizza).
To get the best from this function, follow the
indications on the relative cooking table.
FORCED AIR + STEAM
Combining the properties of steam with those
of the forced air, this function allows you to cook
dishes pleasantly crispy and browned outside, but
at the same time tender and succulent inside. To
achieve the best cooking results, we recommend
to select STEAM 1 level for bread and desserts, and
STEAM 2 for meat, fish and vegetables.
FORCED AIR
For cooking different foods that require the
same cooking temperature on several shelves
(maximum three) at the same time. This function can
be used to cook different foods without odours being
transferred from one food to another.
TRADITIONALS FUNCTIONS
• CONVECT BAKE
For cooking meat, baking cakes with fillings on
one shelf only.
• TURBO GRILL
For roasting large joints of meat (legs, roast beef,
chicken). We recommend using a drip tray to
collect the cooking juices: Position the pan on any
of the levels below the wire shelf and add 500 ml
of drinking water.
• FROZEN BAKE
The function automatically selects the ideal
cooking temperature and mode for 5 different
types of ready frozen food. The oven does not
have to be preheated.
• SPECIAL FUNCTIONS
»AIR FRY
This function allows you to cook French fries,
chicken nuggets and more using less oil,
resulting pleasantly crispy. Heating elements
cycle to properly heat the cavity, while the
fan circulates hot air. Best expected cooking
results can be achieved only by using an Air
Fry tray (provided with some models). Position
the food on the Air Fry tray in a single layer
and follow Air Fry Cooking Table instructions
for best performances. Avoid using more than
one tray to prevent uneven cooking.
»RISING
For optimal proving of sweet or savoury
dough. To maintain the quality of proving, do
not activate the function if the oven is still hot
following a cooking cycle.
»DEFROST
To speed up defrosting of food. Place food on
the middle shelf. Leave food in its packaging
to prevent it from drying out on the outside.
»KEEP WARM
For keeping just-cooked food hot and crisp.
»ECO FORCED AIR
For cooking stuffed roasting joints and
fillets of meat on a single shelf. Food is
prevented from drying out excessively by
gentle, intermittent air circulation. When
this ECO function is in use, the light will
remain switched off during cooking. To use
the ECO cycle and therefore optimise power
consumption, the oven door should not be
opened until the food is completely cooked.
CONVENTIONAL
For cooking any kind of dish on one shelf only.
GRILL
For grilling steaks, kebabs and sausages,
cooking vegetables au gratin or toasting bread. When
grilling meat, we recommend using a drip tray to
collect the cooking juices: Position the tray on any
of the levels below the wire shelf and add 500 ml of
drinking water.
FAST PREHEAT
For preheating the oven quickly.
TIMERS
For editing function time values.
MINUTEMINDER
For keeping time without activating a function.
CLEANING
• DR AIN
For draining the boiler in order to prevent residual
water remaining in there when the appliance will
not be used for a certain period of time.
• DESCALE
For removing limescale deposits from the boiler.
We recommend using this function at regular
intervals. If yuo do not, a message will appear on
the display reminding you to clean the oven.
• SMART CLEAN
The action of the steam released during this
special low-temperature cleaning cycle allows
dirt and food residues to be removed with ease.
Pour 200 ml of drinking water on the bottom of
the oven and only activate the function when the
oven is cold.
Product Specifications
| Brand: | Whirlpool |
| Category: | Oven |
| Model: | AKZ9S 8220 IX |
