Whirlpool AKP 460/IX Manual
Read below 📖 the manual in Italian for Whirlpool AKP 460/IX (24 pages) in the Oven category. This guide has been helpful for 4 people and has been rated 4.5 stars on average by 2 users
Page 1/24
EN
Quick guide
PRODUCT DESCRIPTION
1. Control panel
2. Fan
3. Shelf guides
(the level is indicated on the front of the
oven)
4. Door
5. Upper heating element/grill
6. Lamp
7. Identication plate
(do not remove)
8. Bottom heating element
(non-visible)
1
2
3
4
7
8
6
5
CONTROL PANEL
1 2 5 63 2 4
1. SELECTION KNOB
For switching the oven on by selecting a function. Turn to the position
to switch the oven o.
2. - / + BUTTONS
To decrease or increase the value shown on the display.
3. TIME BUTTON
For selecting the various settings: duration, cooking end time, timer.
4. DISPLAY
5. THERMOSTAT KNOB
Turn to select a desired temperature, activating the selected function.
6. LED THERMOSTAT / PREHEATING
Switches on during the heating process. Switches o once the desired
temperature is reached.
Please note: The knobs are retractable. Press the knobs in the middle and
they pop up.
ACCESSORIES
The number and type of accessories may vary depending on which model
is purchased. Other accessories that are not supplied can be purchased
separately from the After-sales Service.
WIRE SHELF. Use to cook food or as a support
for pans, cake tins and other ovenproof items
of cookware.
DRIP TRAY. Use as an oven tray for cooking
meat, sh, vegetables, focaccia, etc. or position
underneath the wire shelf to collect cooking
juices.
BAKING TRAY. Use for cooking all bread and
pastry products, but also for roasts, sh en
papillotte, etc.
Insert the wire shelf horizontally by sliding it across the shelf guides,
making sure that the side with the raised edge is facing upwards.
Other accessories, such as the drip tray and the baking tray, are
inserted horizontally in the same way as the wire shelf.
SLIDING RUNNERS.*
To facilitate inserting or removing accessories.
Remove the protective plastic o them. Place the drip
tray on the telescopic runners xing it between the
rear and front fastener.
The sliding runners can be tted on any level. To t the sliding runners,
fasten the upper clip of the runner to the shelf guide and slide it along as
far as it will go (1). Lower other clip into position. To secure the guide, press
the lower portion of the clip rmly against the shelf guide (2). Make sure
that the runners can move freely. Repeat these steps on the other shelf
guide on the same level.
1 2
REMOVING AND REFITTING THE SHELF GUIDES
To remove the shelf guides, lift the guides up and then gently pull the
lower part out of its seating: the shelf guides can now be removed.
To ret the shelf guides, rst t them back into their upper seating.
Keeping them held up, slide them into the cooking compartment, then
lower them into position in the lower seating.
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
* Available only on certain models
FIRST TIME USE
1. SETTING THE TIME AND THE TONE
You will need to set the time of the day when you switch on the
appliance for the rst time: “AUTO” and “0.00” ash on the display.
A
U
T
O
To set the time of day, press buttons and at the same time: Set the
time of day using the and buttons.
Press the time button to conrm.
Having selected the desired time value, it is possible to change the
alarm tone: the display shows “ton 1”.
A
T
O
To select the desired tone, press button , then press the time button
to conrm.
Please note: To change the time of the day afterwards for example
following lengthy power outages, proceed as described above.
2. HEAT THE OVEN
A new oven may release odours that have been left behind during
manufacturing: this is completely normal. Before starting to cook food,
we therefore recommend heating the oven with it empty in order to
remove any possible odours.
Remove any protective cardboard or transparent lm from the oven
and remove any accessories from inside it.
Heat the oven to 250 °C for about one hour. The oven must be empty
during this time. Follow the instructions for setting the function
correctly.
Please note: It is advisable to air the room after using the appliance for the
rst time.
FUNCTIONS & DAILY USE
. SELECT A FUNCTION
To select a function, turn the to the symbol for the selection knob
function you require.
OFF
For switching o the oven.
LAMP
To switch the oven light on.
CONVENTIONAL
For cooking any kind of dish on one shelf only.
Leavened cakes 160 - 180 35 - 55 2
Biscuits/tartlets 170 - 180 15 - 40 3
Frozen Pizza 250 10 - 15 2
Lasagne / baked pasta / canneloni /
ans 190 - 200 40 - 65 2
Lamb / veal / beef /pork 190 - 200 90 - 1101 kg 2
Chicken / rabbit / duck 190 - 200 65 - 851 kg 2
Baked sh / en papillote 0,5 kg
(llets, whole) 180 - 200 40 - 60 2
SMART CLEAN (Only in some models)
The action of the steam released during this special low-
temperature cleaning cycle allows dirt and food residues to be
removed with ease. This function should be activated only when the
oven is cold and after having poured 200 ml of drinking water into the
bottom of the oven. Set the timer for 30 minutes and the temperature
at 90°C. Once the cycle is nished, wait about 15 minutes before
opening the door.
CONVECTION BAKE
For cooking meat or baking cakes with liquid centre on a single
shelf. This function delivers an even, golden, crisp top and base.
Filled cake 180 - 200 50 - 60 2
Salty cakes 180 - 200 35 - 55 2
Stued vegetables 175 - 200 40 - 60 2
GRILL
For grilling steaks, kebabs and sausages, cooking vegetables au
gratin or toasting bread. When grilling meat, we recommend using a
drip tray to collect the cooking juices: position the tray on any of the
levels below the wire shelf and add 500 ml of drinking water.
Toasted bread 200 2 - 5 4
Fish llets / slices 30 - 40 *200 4 3
Sausages / kebabs / spare ribs /
hamburgers 200 30 - 50 * 4 3
* Turn food halfway through cooking
TURBO GRILL
For roasting large joints of meat (legs, roast beef, chicken). We
recommend using a drip tray to collect the cooking juices: position
the pan on any of the levels below the wire shelf and add 500 ml of
drinking water.
Roast chicken 1-1,3 kg — 55 - 70 *200 2 1
Roast beef rare — 30 - 40 **1 kg 200 2
Roast potatoes — 45 - 55 **200 2
* Turn food halfway through cooking
** Turn food two thirds of the way through cooking (if necessary).
DEFROST
For defrosting food more quickly. Place food on the middle shelf.
Leave food in its packaging in order to prevent it from drying out on
the outside.
EN
HOW TO READ THE COOKING TABLES
The table lists recipes , if preheating is needed , temperature
, cooking time , accessories and level suggested for cooking.
Cooking times start from the moment food is placed in the oven,
excluding preheating (where required). Cooking temperatures and times
are approximate and depend on the amount of food and the type of
accessory used. Use the lowest recommended settings to begin with and,
if the food is not cooked enough, then switch to higher settings. Use the
accessories supplied and preferably dark-coloured metal cake tins and
baking trays. You can also use Pyrex or stoneware pans and accessories,
but bear in mind that cooking times will be slightly longer.
Accessories showed:
Wire Shelf
Cake tin on wire shelf
Drip tray / baking tray
Cake tin on wire shelf or drip tray / baking tray
Tray with water
. ACTIVATE A FUNCTION
To start the function you have selected, turn the to set thermostat knob
the temperature you require.
To interrupt the function at any time, switch o the oven, turn the
selection knob and the thermostat knob to and .
Once the function has been activated, the LED thermostat lights up,
switching o again when the oven reaches the selected temperature:
At this point, place the food inside and proceed with cooking.
Please note: placing the food in the oven before preheating has nished
may have an adverse eect on the nal cooking result.ù
. USING THE ELECTRONIC PROGRAMMER
By pressing the it is possible to select various mode to keep time button
or program the cooking time.
Please note: After few seconds without any interaction, a buzzer sounds
and all settings will be conrmed.
SETTING THE MINUTE MINDER
This option does not interrupt or activate cooking but allows you to
use the display as a timer, both while a function is active and when the
oven is o.
To activate the timer, long press the : the time button symbol ashes
on the display (1).
Use the and buttons to set the desired duration: the countdown
begins after a few seconds. The display shows the time of the day and
the remains lit, conrmating the timer has been set (2).
At the end, long press the to deactivate the alarm. time button
1
A
T
O
2
A
T
O
Please note: To view the countdown and change it if necessary, press the
time button 2 seconds again.
SETTING THE DURATION
After selecting and activating the function, in order to stop it
automatically, you can set a cooking time.
Long press the : the time button symbol ashes (3).
Press the again: DUR and AUTO will ash on the display (4).time button
Set the duration using the and buttons.
After a few seconds, the display will show the time of the day while
AUTO remains lit, conrming the setting (5).
3
A
T
O
4
A
U
T
O 5
A
U
T
O
Please note: To see how much time is left and change the remaining
cooking time repeat the steps above.
When the set cooking time is over, an alarm will sound and the cooking
will be stopped (6).
6
A
U
T
O
Long press the to deactivate the alarm. Return the time button selection
knob and thermostat knob to and to switch o the oven.
Product Specifications
| Brand: | Whirlpool |
| Category: | Oven |
| Model: | AKP 460/IX |
