Page 1/1
Technische Information/Technical Data
Tonsäule/Sound Column AL 10/1
Vielen Dank für den Kauf eines WHD-Produkts. Nehmen Sie sich bitte einen Moment Zeit für diese kurze
technische Information. Beachten Sie bitte ganz besonders die mit „!“ gekennzeichneten Hinweise!
Vielen Dank für den Kauf eines WHD-Produkts. Nehmen Sie sich bitte einen Moment Zeit für diese kurze
technische Information. Beachten Sie bitte ganz besonders die mit „!“ gekennzeichneten Hinweise!
Falls Sie bei der Montage Verbesserungsvorschläge entdecken, nehmen wir diese dankbar entgegen und
überprüfen gerne, ob wir sie Ãn unsere Produkte einbringen können.
Falls Sie bei der Montage Verbesserungsvorschläge entdecken, nehmen wir diese dankbar entgegen und
überprüfen gerne, ob wir sie Ãn unsere Produkte einbringen können.
Thank you for buying a WHD product. Please read this manual carefully,especially the ! marked parts. Thank you for buying a WHD product. Please read this manual carefully,especially the ! marked parts.
Technische Daten / Specifications:Technische Daten / Specifications:
AL 10/1 - 4 AL 10/1 – T12
Nennbelastbarkeit / Load rating : 15 W 12W
Schalldruckpegel / Sound pressure level:
1 W / 1m :
bei Nennleistung / at rated output:
94 dB
105 dB
94 dB
105 dB
Ãœbertragungsbereich / Frequency range (-3dB): 220-16 000 Hz 220-16 000 Hz
Schutzart / Type of protection: IP 54 IP 54
Montage / Installation:
1. Befestigen Sie die beiden Winkel an der Wand.
Fix the mounting angles on the wall.
2. Montieren Sie die Tonsäule an den Winkeln.
Mount the sound column at the mounting angles.
Anschluß / Connection:
3. Schließen Sie die Tonsäule wie folgt an.
Version
Farbe / Colour
AL 10/1 - 4 AL 10/1 – T12
Blau / blue oder / or
Gelb-Grün / yellow-green 0 0
Braun / brown 100 V / 12 W
Gelb / yellow 100 V / 6 W
Grün / green 100 V / 3 W
Weiss / white 4 Ohm 100 V / 1,5 W
Technische Änderungen vorbehalten / Technical modifications reserved: 03/02
