Voxicon S-W25B Manual
Voxicon
Cradle/docking station
S-W25B
Read below 📖 the manual in Italian for Voxicon S-W25B (1 pages) in the Cradle/docking station category. This guide has been helpful for 8 people and has been rated 4.5 stars on average by 2 users
Page 1/1
S-W25B
Volume Up
Press and Hold
Press and Hold
Press “ ” “ ” buttons simultaneously LED Indicator ，
fast blinking blue to disconnect the current connected
device, and go into new Bluetooth-paring mode.
Volume Down
S-W25B
Flash Red
• Bluetooth Version: 4.2
• Suport:A2DPV1.2,AVRCPV1.4,HPV1.6,HSPV1.2
• Wireless work distance:10 meters
• Rated Power: 2 x 12.5W
• Driver Unit: 2 xφ48mm (4Ω,2x15W)
• Frequency response: 80Hz-16kHz
• Signal-to-noise ratio: >70dB
• Battery type: Lithium-ion (7.2V/2000mAh)
• DC input voltage/current: MICRO USB DC 5V/0.5A - 2A
• Playtime: 7-11 hours (varies by volume level and content)
• Battery charge time: 2.5 hours
• Dimensions: 186.6 x78x78 mm
• Weight: 620g
The TWS technology enables you to use two speakers
pairing via Bluetooth to create a wireless dual-channel
system to deliver true stereo sound effect.
TWS connection operation
1.Place the two speakers near each other (the distance
should not be over 10 meters).
2.Power on the two speakers, double click the button
button on one speaker as MASTER speaker (playback
left channel ), the LED indicator fast blinking blue and
green, then the two speaker will pair to each other
automatically (The other speaker will be as SLAVE
speaker and playback right channel)
3.Once paired, the MASTER speaker LED indicator
slow flash blue.
TWS (True Wireless Stereo)
Function
Disconnect the TWS connection
IPX6 Water-Resistant Feature
Press“ ” “ ” button on one of the speaker simultaneously ,
until LED Indicator fast blinking blue to disconnect the
TWS connection.
1× Textil strap
This Speaker is IPX6 Water-Resistant for rainfall, spills,
or water jets,but do NOT submerge it in water or liquids.
IMPORTANT Note - To ensure the speaker is prepared to
use for water-resistant,remove all the cable connections and
close the port protection cover tightly.
Reset the speaker: If the function buttons without working,
disconnect the charging cable, place a small pin(Φ<3mm)
into the reset key and hold it for 2 seconds until the LED light off.
Sound mode
Mode Change Button : Outdoor/Indoor
Double click the play/pause button to change the sound
mode.The LED indicator slowly flash blue in outdoor mode,
and the LED indicator keep solid blue in indoor mode.
Remark: This speaker’s default mode is indoor.
Volume UP/Next track
Volume Down/Previous track
Power-on/off
Play/Pause/Mode Change
USB Changing Port
Aux-In/Reset key
LED Indicator
LED Indicator
Microphone
Product Specifications
| Brand: | Voxicon |
| Category: | Cradle/docking station |
| Model: | S-W25B |
