Vonyx CMS300S Manual
Vonyx
Microphone
CMS300S
Read below 📖 the manual in Italian for Vonyx CMS300S (2 pages) in the Microphone category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/2
CMS300 Series Studio Microphone S et
Ref. nr.: 173.5 , 173.514, 173.516 12
INSTRUCTION MANUAL
V1.1
Congratulations to the purchase of this Vonyx product. Please read this manual thoroughly prior to using the product in order to
benet fully from all features. Follow the instructions in order not to invalidate the warranty. Take all precautions to avoid re
and/or electrical shock. Keep the manual for future reference.
UNPACKING INSTRUCTION
CAUTION! Immediately upon receiving the product, carefully unpack the carton, check the contents to ensure that all parts are
present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if
any parts appear damage from shipping or the package itself shows signs of mishandling. Save the package and all packing
materials. In the event that the product must be returned to the factory, it is important that the product be returned in the original
factory box and packing.
MICROPHONE CONNECTION
STAND ASSEMBLY INSTRUCTIONS
1. Install the base of the stand on to, for example, a tabletop.
2. Attach the suspension arm link to the base stand.
3. Tighten the nut once your preferred suspension arm direction has been determined.
4. Attach the arm to the suspension arm li . nk
5. Attach the shock mount the suspension arm. Use the adapter of the microphone to
6. holder to enable mounting of the shock mount (picture right).
7. Adjust the height of the arm to your preferred height.
8. Put the microphone into the clamp ring of the ock mount. sh
9. Optional: attach the pop lter to the stand to eliminate popping and sibilance sound.
SPECIFICATIONS
CMS 300
Ref.nr.
173.512
173.5 14
173.516
Frequency response
50Hz- KHz 14
Sensitivity
- dB (+/-2dB) 43
Impedance
200 Ohm
SPL max
120dB
Mic. Power supply
5V via USB
Weig ht
1.95kg
Specications and design are subject to change without prior notice.
www.tronios.com
Copyright © 2022 by Tronios The Netherlands
Product Specifications
| Brand: | Vonyx |
| Category: | Microphone |
| Model: | CMS300S |
