Installation Guide
LPKTVDR1 LP Conversion Kit
for Tuscany Ranges
Description Part Number/Marking Quantity
Rear Surface Burner (B) 072154-000 / 78 1
Rear Surface Burners (C) 072156-000 / 105 3
Front Surface Burner (D) 072155-000 / 120 4
Conversion label PF030377 1
LPKTVDR Conversion Instructions 073988-000 1
LP Ori ce Conversion Kit Contents
NOTE: Depending on the model being converted, some of the ori ces may not be used.
IMPORTANT - Please Read and Follow!
WARNING
FIRE/EXPLOSION
HAZARD
If the information in this
guide is not followed exactly, a fi re or
explosion may result causing property
damage, personal injury or death.
WHAT TO DO IF YOU SMELL GAS:
• try to light any appliance.DO NOT
• touch any electrical switch.DO NOT
• use any phone in your building.DO NOT
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fi re department.
Installation and service must be performed
by a qualifi ed installer, service agency, or
the gas supplier.
CAUTION
Before placing the appliance
into operation, always check for
gas leaks with a soapy water
solution or other acceptable method.
DO NOT use an open fl ame to check for
leaks.
CAUTION
Be sure the electric power
is turned off at the breaker
box while the unit is being
converted.
22
Regulator Conversion
LP
Orientation
NAT
LP
Natural
Orientation
NAT
LP
Apply sideways finger pressure
to remove pin from cap.
NAT
LP
conversion
conversion
•Remove hex nut from top of regulator.
•Unsnap plastic plunger from hex nut.
• Reverse plunger and reinstall onto hex nut by pressing
rmly.
NOTE: Plunger is marked “NAT” or “LP”.
Converted fuel type will be shown on the lower portion
of plunger.
• Reinstall hex nut onto regulator in con guration desired.
Ori ce
Locations
48” W /6 Surface Burners 48” W /4 Surface Burners/Griddle48” W /4 Surface Burners/Induction
8,500 Nat/
7,700 LP
13,500 Nat/
12,500 LP
N/A
N/A
N/A
B B
B
C C C
C
D D D D D
D D
7,700 LP
(2.5kW)
7,700 LP
(2.5kW)
12,500 LP
(4.0 kW
12,500 LP
(4.0 kW
12,500 LP
(4.0 kW
18,500 LP
(6.0 kW) 18,500 LP
(6.0 kW)
18,500 LP
(6.0 kW)
18,500 LP
(6.0 kW)
18,500 LP
(6.0 kW)
18,500 LP
(6.0 kW)
18,500 LP
(6.0 kW)
8,500 Nat/
7,700 LP
13,500 Nat/
12,500 LP
20,500 Nat/
18,500 LP
20,500 Nat/
18,500 LP
13,500 Nat/
12,500 LP
66” W /8 Surface Burners
13,500 Nat/
12,500 LP
20,500 Nat/
18,500 LP
20,500 Nat/
18,500 LP
66” W /6 Surface Burners/Griddle
8,500 Nat/
7,700 LP
20,500 Nat/
18,500 LP
20,500 Nat/
18,500 LP
13,500 Nat/
12,500 LP
2 kW
13,500 Nat/
12,500 LP
20,500 Nat/
18,500 LP
8,500 Nat/
7,700 LP
20,500 Nat/
18,500 LP
66” W /6 Surface Burners/Induction
20,500 Nat/
18,500 LP
13,500 Nat/
12,500 LP
13,500 Nat/
12,500 LP
20,500 Nat/
18,500 LP
BC C C B C C
D D D D D DD
BC C
D D D
7,700 LP
(2.5kW)
36” W /4 Surface Burners
12,500 LP
(4.0 kW
18,500 LP
(6.0 kW)
B C
DD
18,500 LP
(6.0 kW)
33
Surface Burner Conversion
Surface Burner Conversion
-Locate appropriate ori ce
-Remove screw (Item #1) at-head screwdriver.
- Lay the burner ange to side - do not disconnect the igniter wire.(Item
#2).
-Use a nut driver to remove ori ce (Item #3).
-Replace with correct ori ce - refer to next page.
Tech tip: Tape can be applied to the inside of the socket to assist in the
removal of the surface burner ori ces. This can prevent the
ori ces from falling into the range during removal.
- After replacing the ori ce, replace Item#2 burner ange.
-Reinstall screw and reverse procedure to reassemble.
NOTE: For proper placement of the burner head, rotate until burner
head seats into groove.
Item #1
Item #2
Item #3
Remove grates, surface burner caps and frenchtop (if applicable)
