VICTOR
1776
12 DIGIT HEAVY DUTY PRINTING CALCULATOR
INSTRUCTION MANUAL
1
TABLE OF CONTENTS
OPERATIONS AND MAINTENANCE ........... ............................................... .2 …. …….. .....
ACTIVATE BACKUP BATTERY….………………………………………………………..….2
REPLACING INK . .................... ......................................... 2 RIBBON…… …… ……….
HOW TO FEED THE PAPER TAPE… …… ……… …3........... ...... ..................................
BATTERY REPLACEMENT…………………………..………………………………….…...4
KEYBOARD LAYOUT. ............................... ......................................... ....…… ………. .5
SLIDE SWITCH FEATURES.......................................... ......................... ……… …….6
KEY FEATURES............................................................... ..................... ……… ……..8
TROUBLESHOOTING……………………………………………………………………….10
APPLICATION EXAMPLES ................................... .................……………… …. ……11
SETTING DATE AND TIME……………………………………………………………...28,29
TECHNICAL SPECIFICATION……………….……………………………..…………..30
WARRANTY ………………………………………………………………………….………31
2
OPERATIONS AND MAINTENANCE
Before Turning On - Please remove ribbon-cushion placed on a ribbon and check the rating
label on the bottom to see if the rated voltage corresponds to the local voltage before plug in AC
cord.
Note: Ribbon cushion is located under
printer cover.
CAUTIONS
1. Do not place the machine in hot, dusty or damp locations.
2. To clean the housing use a silicon-treated cloth. Do not use water or detergents.
3. not place anything on the housing, particularly on the head of the printer mechanism. Do
4. Turn off the power switch before removing the plug from AC wall outlet.
5. Turn the power switch off while not in use.
6. The socket-outlet shall be installed near the equipment and shall be easily accessible.
ACTIVATE BACKUP BATTERY
Before start using the calculator, please remove the insulation paper below the backup battery.
1. Turn the AC power switch OFF and remove the battery compartment cover located on
the bottom case.
2. Remove the insulation paper located below the backup battery.
3. PRESS THE RESET SWITCH.
4. Replace the battery compartment cover.
5. Turn ON the AC power switch.
6. Program the date and time according to the instruction manual.
REPLACING INK RIBBON
Your calculator is shipped with a 2-color ribbon already in place. You do not need to install or
1
REMOVE BEFORE USING THE MACHINE
Depress Reset in Battery Compartment
Program Date & Time See Operator Manual –
Backup Battery
CR2025
Insulation
Paper
Reset Button
3
2
