Assembly and Setup Instructions
version 0.0
Note:
If you cannot understand these instructions or are concerned about safety of the installation
Contact a qualified contractor or contact VFI at 1-877-834-3876.
Confirm all hardware is included before you begin assembly.
Not all hardware supplied will be used depending on the manufacturer of your display/s.
Page 1
of 6
VIDEO FURNITURE INTERNATIONAL
190 Don Hillock Drive Aurora , Ontario L4G 0G9 www.video-furn.com
Toll Free: 1-877-834-3876 Fax: 1-905-751-1488 Local:905-751-1459
T526 Collaboration
Table
TWO (2) PEOPLE ARE REQUIRED TO UNPACK AND ASSEMBLY THIS PRODUCT
#2 Phillips (+)
Screwdriver
7/16 and 13mm
Wrench or Socket
Panel Bolt
1.5"
(6)
Cam Pin
(16)
Cam
Stickers
(20)
8-30mm
Wooden dowel
(6)
Base 1
(1)
Base 2
(1)
T526-Top
(1)
Island Large
*cut outs not shown*
(1)
Back
assembly
(1)
PM2 MOUNT S/D/XL
(1)
*SINGLE SHOWN*
1.00" Mat
Cam
(8)
Page 2
of 6
SUPPLIED PARTS
SUPPLIED HARDWARE
REQUIRED TOOLS (not included)
Cordless drill
w/ #2 Phillips (+)
bit
.75" Mat
Cam
(12)
TV32-52 / TV52 - 70
Hardware bag
(1)
TP-1000
Hardware bag
(1)
8
.75"
12
4
1"
8
4
x4
16
In order to
TIGHTEN
the cams, turn the
screwdriver and the cam
CLOCKWISE
In order to
LOOSEN
the cams, turn the
screwdriver and the cam
COUNTER CLOCKWISE
The T526 Series table will require you to use this
type of operation throughout the assembly
process
Page 3
of 6
Direction of
pieces
Required to go under the
table
43
12
