V-Tac VT-55W Manual
Read below 📖 the manual in Italian for V-Tac VT-55W (4 pages) in the Lamp category. This guide has been helpful for 9 people and has been rated 4.5 stars on average by 2 users
Page 1/4
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
LED FLOOD LIGHT WITH SOLAR PANEL
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
TECHNICAL DATA
MODEL VT-55W VT-102W
SKU 23438 23439
LUMEN 1000Lm 1800Lm
SOLAR PANEL 10W 15W
COLOR
TEMPERATURE 4000K 4000K
DC VOLTAGE 6V 6V
CHARGING TIME 6-8H 6-8H
WORKING TIME 12H 12H
BATTERY 3.7V, 8000mAh 3.7V, 12000mAh
BATTERY TYPE 21700 Lithium Iron
Phosphate Battery
21700 Lithium Iron
Phosphate Battery
OPERATION
TEMPERATURE` -10°C to +50°C -10°C to +50°C
SOLAR PANEL
COLOR BLACK BLACK
FLOOD LIGHT
DIMENSION 191x241x73mm 191x241x73mm
SOLAR PANEL
DIMENSION 210x340mm 390x230mm
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR
code to access the
manual in multiple
languages.
PACKAGE CONTENT
REMOTE INSTRUCTIONS
• Please make sure to turn o the power before starting the installation.
• Installation should only be done by a certified electrician.
• The light source of this luminaire is not replaceable, when the light source
reaches its end of life the whole luminaire should be replaced.
• If the external flexible cable or cord of this luminaire is damaged, it shall be
exclusively replaced by the manufacturer or his service agent or a similar
qualified person in order to avoid a hazard.
WARNING
1x Light 1x Solar Panel
Turn o the light
Turn on the light Enter the motion sensor
mode or exit the mode
Full bright
Reduce brightness
Increase brightness
Half bright
Turn on at night
automatically by light control If it is the steady on mode,turn on
aer dark for 5H,then turn o;
If it is the motion sensor
mode,turn on aer dark for
5H,then keep the 10% bright-
ness;
If it is the steady on mode,turn on
aer dark for 3H,then turn o;
If it is the motion sensor
mode,turn on aer dark for
3H,then keep the 10% brightness; If it is the steady on mode,turn on
aer dark for 8H,then turn o;
If it is the motion sensor
mode,turn on aer dark for
8H,then keep the 10% brightness;
1x Remote 1x User Manual 4x Screw
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTIONS
ADDITIONAL INSTRUCTIONS
A. Batterry replacement
1
4 5
2 3
• Install the solar panel bracket.
• Locate and fix the floodlight.
• Locate and fix the solar panel, adjusting the solar panel in a proper angle and make sure it
can get the sunlight directly in a long time.
• Connect the cable between floodlight and solar panel, make sure it›s connected tightly.
• Use the remote controller to try and make sure it can work well.
Product Specifications
| Brand: | V-Tac |
| Category: | Lamp |
| Model: | VT-55W |
