V-Tac VT-1147 Manual
Read below 📖 the manual in Italian for V-Tac VT-1147 (6 pages) in the Lamp category. This guide has been helpful for 4 people and has been rated 4.5 stars on average by 2 users
Page 1/6
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
INSTRUCTION MANUAL
SOLAR LED WALL LIGHT
WITH SENSOR
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
TECHNICAL DATA
MODEL VT-1147
SKU 10402
LUMENS 220 Lm
SOLAR PANEL DC 5.5V,
BATTERY 2200mAh
CHARGING TIME 8-10 Hour
WORKING TIME 6-8 Hours
BULB WATTS 5.5 W
COLOR TEMPERATURE 3000K
SENSOR TYPE PIR Sensor
SENSOR DEGREE 90-110°
DIMENSION 155x299x130mm
MATERIAL Aluminium+PC
This marking indicates that this
product should not be disposed of
with other household wastes.
WARNING
INSTALLATION DIAGRAM
1. Please make sure to turn o the power
before starting the installation.
2. Installation should be done by certified
electrician.
1 2 3
4 5 6
7
High Light High LightLow Light Standby Time
1. Mode A:
Long press 3s start
(Turn on) Low light.
2. Mode B:
When sensor on high light
25s, then low light.
3. Mode C:
When sensor on high light
25s, then standby time.
4. Mode D:
(Turn o)
INSTALLATION INSTRUCTION
1. Drill two holes on the wall and insert two plastic expansion bolts in it.
2. Fix the metal plate on the plastic expansion piece with self-tapping screws.
3. Fix the lamp body on the plate and tighten the screws.
4. Switch on and test.
MAINTENANCE & WARNING
• Do not use solvents, petrol, etc. Otherwise the light will be damaged.
• Clean the light with a dry, lint-free cloth.
• Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee
flawless function of the product.
• Especially during the winter, keep the product free from snow and ice.
• Confirm installation direction is correct (solar panel should be at top)
• Confirm no objects blocking the solar panel to receive sunlight
• Keep away from the fire.
• Don’t immerse in the water
FUNCTION OF SENSOR
1. Long press 3s start (turn on) low light10%
2. Turns 100% brightness when motion is detected and 10% light when people go away
3. Turns 100% brightness when motion is detected and light turn o when no one come in.
4. Turn o.
Product Specifications
| Brand: | V-Tac |
| Category: | Lamp |
| Model: | VT-1147 |
