Page 1/3
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
SOLAR BUG ZAPPER
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
TECHNICAL DATA
MODEL VT-3215
SKU 23459
RATING POWER 5W
UV LIGHT 2W
SOLAR PANEL 1.3W
BATTERY CAPACITY 2200mAh
BATTERY TYPE 18650, Li-Ion Battery
CHARGING TIME 8-10 Hours (Solar Charge)
4 Hours (Type-C Charging)
WORK TIME 4 hours (Max)
COVER AREA 20 Sqm
HIGH VOLTAGE 1000V
IP RATING IP24
MATERIAL ABS
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to access the manual
in multiple languages.
DIMENSION
TABLETOP 128x128x344mm
DIMENSION
STANDING 128x128x672mm
3 TYPE OF INSTALLATIONS
PRODUCT PARTS
TABLETOP SPIKEHANG
Mono Solar Panel
Silicon Handle
Body Switch
ABS Plastic Housing
Collection Tray
Tabletop Base
Type C Port
High Voltage Grid
T5 2W LED Light
Ground Stake
This marking indicates that this
product should not be disposed
of with other household wastes.
MAINTENANCE & WARNING
• Do not use solvents, petrol, etc. Otherwise the light will be damaged.
• Clean the light with a dry, lint-free cloth.
• Check the solar panel for dirt regularly. If dirt or is present remove it to guarantee
flawless function of the product.
• Especially during the winter, keep the product free from snow and ice.
• Confirm installation direction is correct (solar panel should be at top).
• Confirm no objects blocking the solar panel to receive sunlight.
• Keep away from the fire.
• Don’t immerse in the water.
