V-Tac VT-2833 Manual

V-Tac Lamp VT-2833

Read below 📖 the manual in Italian for V-Tac VT-2833 (2 pages) in the Lamp category. This guide has been helpful for 5 people and has been rated 4.5 stars on average by 2 users

Download PDF
Page 1/2
TECHNICAL DATA
MODEL VT-2825 VT-2833
SKU 23155, 23156 23157, 23158
WATTS 20W 28W
LUMENS 1408 Lm 2500 Lm
INPUT VOLTAGE AC 100~240V, 50/60 Hz
BEAM ANGLE 25° 25°
PF >0.7 >0.9
LIFE SPAN 25,000 Hours 25,000 Hours
ON/OFF CYCLE 15,000 Times 15,000 Times
IP RATING IP20 IP20
MATERIAL Aluminium Aluminium
DIMENSION Ø148x75 mm Ø178x87 mm
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
INSTRUCTION MANUAL
LED COB DOWN LIGHT
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
• Please make sure to turn o the power before starting the installation.
• Installation must be performed by a qualified electrician.
• The light source of this luminaire is not replaceable, when the light
source reaches its end of life the whole luminaire should be replaced.
• For indoor use only.
1. Confirm the installation position of the bracket.
2. Drill a hole.
3. Plug in expansion bolt.
4. Fix the bracket (Included) on the ceiling with screws.
5. Connect the wiring as per the wiring diagram.
6. Fix the downlight onto the bracket with screws.
7. Switch on the power and test.
WARNING
INSTALLATION DIAGRAM
INSTALLATION INSTRUCTIONS
1 3
4 5 6
This marking indicates that this
product should not be disposed of
with other household wastes. Caution, Risk of electric shock
Luminaires not suitable
for covering with thermally
insulating material. Replaceable control gear
by a professional
Non-replaceable
light source
2

Product Specifications

Brand: V-Tac
Category: Lamp
Model: VT-2833
