Page 1/2
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code
to access the manual in multiple languages.
INSTRUCTION MANUAL
LED WATERPROOF FITTING
INTRODUCTION & WARRANTY
TECHNICAL DATA
WARNING
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source of this luminaire is not replaceable, when the light source reaches its end of life the
whole luminaire should be replaced.
4. If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by
the manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
MODEL SKU LUMENS CRI DFWATTS BEAM
ANGLE INPUT POWER MATERIAL DIMENSION
MAX
CONNECTABLE
UNITS
VT-1253 10220
10221 36W 4320 Lm ≥80 120° AC:220-240V, 50/60 Hz PC+ABS 1200x64x60mm 10 pcs≥0.9
VT-1254 10222
10223 48W 5760 Lm ≥80 120° AC:220-240V, 50/60 Hz PC+ABS 8 pcs≥0.9 1500x64x60mm
This marking indicates that this product
should not be disposed of with other
household wastes.
Caution, risk of electric shock.
INSTALLATION INSTRUCTION
1. Take the 2 pcs stainless steel brackets out from
accessories bag,fix them onto the ceiling by
oered screws and expansion tubes.
MODEL L1
VT-1253 790±30mm
VT-1254 1090±30mm
1
2
4
3
5
2. Open junction box cover of the body with screwdriver.
3. Fasten the waterproof connector clockwise.Insert cable through the waterproof connector and wire
it into terminal block. Make sure L and N are wired to correct holes.
(LIVE = BROWN; NEUTRAL = BLUE).
4. Cover back to junction box cover,install the lamp to the ceiling clips.
5. Hanging installation type reference. (Suspension clips need to be purchased separately)
