Page 1/3
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INSTRUCTION MANUAL
LED MAGNETIC TABLE LAMP
UP & DOWN LIGHT
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL VT-10115
SKU 23410, 23411
POWER 2.5W+0.5W
RATED INPUT 5V
LUMENS 220+80Lm
BEAM ANGLE 45°
CRI ≥80
PROTECTION RATING IP20
LIFE SPAN 25,000 Hours
STEPLESS DIMMABLE 10-100%
MATERIAL Metal+ABS+PC
DIMENSION 353x110
BATTERY CHARGING TIME WORKING TIME
1800 mAh
Li-ion Battery 2-3 Hours Maximum Light >4 Hours
Minimum Dark > 15 Hours
Glue base
Magnetic ball head
Metal bracket
ABS holder
Magnetic ball head
USB-C Connector
Magnetic
ball head
On/Oîš›
Dimming Touch Switch
This marking indicates that this
product should not be disposed
of with other household wastes.
PRODUCT STRUCTURE
WARNING
1. Please make sure to turn oîš› the power
before starting the installation.
2. The light source of this luminaire is not
replaceable, when the light source reaches
its end of life the whole luminaire should be
replaced.
3. For indoor use only.
Caution, risk of electric shock.
PACKAGE CONTENTS
OPERATION CAUTIONS
1. Don’t connect with dimming sensing device
2. Don’t use the lamp in a humid or flammable environment.
3. Don’t pull the power plug when your hands are wet to prevent electric shock
4. Don’t cover the lamp with objects to prevent the lamp from being damaged
or causing danger.
Continuously touch the key, the main light changes in turn” on -> low -> medium -> high
-> o” cycle selection.
Power hint: red light when charging, green light when full.
INSTALLATION INSTRUCTION
1. Strong magnetic ball head design (adjust
more angles, illuminate more places)
. 2 Screw the metal
bracket into the base
Table Lamp
LED Lamp Metal
Bracket Clip Glue Base Type-C
Line Instruction
Clip Lamp Wall Lamp
1. Put the lamp close to the ball head and
automatically absorb
2. Find the clamping position,clamp and use
1. Clean the wall,paste the glue base
2. Put the lamp close to the ball head and
automatically absorb
