V-Tac VT-11109 Manual
Read below 📖 the manual in Italian for V-Tac VT-11109 (4 pages) in the Lamp category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/4
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to
access the manual in multiple languages.
INSTRUCTION MANUAL
SOLAR LED WALL LIGHT WITH SENSOR
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
MODEL VT-11109
SKU 11884, 11885, 11886
11887, 11888, 11889
LUMENS 860 Lm
BEAM ANGLE 0-90° (Adjustable)
SOLAR PANEL 5V, 3W Monocrystalline
BATTERY 2600mAh, Li-ion Battery,DC:3.7V
CHARGING TIME 8 Hours
WORKING TIME Max 30 Hours
SENSOR DETECTION
ANGLE 120°
SOLAR PANEL POWER 3 W
SENSOR RANGE 4-5 M
COLOR TEMPERATURE 3000K / 4000K
DIMENSION 150x153x150mm
BODY TYPE Aluminium+PC
This marking indicates that this
product should not be disposed of
with other household wastes.
WARNING
INSTALLATION DIAGRAM
1. Please make sure to turn o the power
before starting the installation.
2. Installation should be done by certified
electrician.
1 2
3 4
5 6 7
0-90°
INSTALLATION INSTRUCTION
SENSOR MODES
MODE 1
MODE 2
1. Power o the device.
2. Drill the hole to the required depth of 30mm.
3. Insert the plastic cap, Place the plastic cap into the hole.
4. Attach the base plate, Secure the base plate to the wall using the
provided screw.
5. Slide the device up and down to fits securely onto the base plate.
6. Adjust the Sensor detection angle. Modify the angle according to
your needs.
7. Power on and test the device.
Safe lighting options. Aer no human movement is detected for 30 seconds, the lights are
automatically lowered to 15Lm brightness. Will automatically turn down the brightness to
15Lm (default setting).
press the switch for 3 seconds while the lamp is turning on, the light will flash 2 times, and
it will be changed to second mode (the lamp is 100% bright when some one is moving,
and automatically turn o aer none is moving within 30s)
Product Specifications
| Brand: | V-Tac |
| Category: | Lamp |
| Model: | VT-11109 |
