INSTRUCTION MANUAL
LED DESIGNER HANGING LIGHT
TECHNICAL DATA
MODEL VT-10126
SKU 23431, 23432
POWER 45W
INPUT VOLTAGE A: 220-240V, 50Hz
CURRENT 1050mA
LUMENS 5500Lm
BEAM ANGLE Sphere 120°
CRI >80
LIFE SPAN 20,000 Hours
ON/OFF CYCLE >15.000 Times
IP RATING IP20
MATERIAL Metal+Silicone
DIMENSION 620x1200 mm
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty
does not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no
warranty against damage to any surface due to incorrect removal and installation of the product. The products
are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This
product is warranted for manufacturing defects only.
WARNING
1. Please make sure to turn o the power before starting
the installation.
2. Installation must be performed by a qualified electrician.
3. For indoor use only
Replaceable (LED Only) light source
by a professional
*This product contains a light source of energy eciency
class<E>, where <E> shall be replaced by the energy
class of the contained light source.
N
INSTALLATION DIAGRAM
3 4
5
1 2
This marking indicates that this product
should not be disposed of with other
household wastes.
Caution, risk of electric shock.
Ø220mm
1200 mm
Ø200mm
Adjustable by pulling
Up/Down
• Mark the Position: Identify the appropriate position on the roof for installation.
• Drill the Hole: Drill a hole at the marked point. Then, insert the screw fixture into the hole.
• Attach the Bracket: Secure the bracket to the roof using screws.
• Wire Connection: Connect the wires as indicated in the diagram.
• Fix the Light Basement: Attach the light basement to the installed bracket.
• Adjust the Light Height: Adjust the height of the light by pulling it up or down as needed.
• Power On: Turn on the power and test the light to ensure proper installation.
HIGHT ADJUSTMENT FUNCTION
INSTALLATION INSTRUCTIONS
