Universal Audio Standard SD-7 Manual
Universal Audio
Microphone
Standard SD-7
Read below 📖 the manual in Italian for Universal Audio Standard SD-7 (2 pages) in the Microphone category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users
Page 1/2
USER GUIDE
Standard Dynamic Microphone
with Mic Modeling
50 mm
113.50 mm
Congratulations SpecificationsGet Hemisphere
Your new SD-7 Standard
Dynamic Microphone with
Hemisphere Mic Modeling is
designed to deliver years of
uncompromising sonic
performance.
The SD-7 is a professional
dynamic studio microphone
suitable for a wide range of
audio applications. With its
hypercardioid polar pattern
and brilliant, punchy tone, the
SD-7 is perfect for capturing
toms, horns, and other high
SPL sources.
Your SD-7 includes Hemisphere
mic modeling, giving you a
collection of the greatest mics
ever made.
Follow these steps to get your
Hemisphere Mic Collection
plug-in:
For complete documentation
and support, please visit
help.uaudio.com
On your computer, visit
uaudio.com/mics/hemisphere
Download, install, and open
the UA Connect application.
Click the + Add Hardware
button in the app and enter
the serial number, which can
be found on the package
or the XLR connector, then
download your plug-in.
1
2
3
Type
Dynamic
Polar Pattern
Hypercardioid
Sensitivity
-54 dB (0 dB = 1V/Pa @ 1 kHz)
Frequency Range
30 Hz - 17 kHz
Output Impedance
600 Ohms
Output Connector
3-pin XLRM
10007532R2
Used electrical and electronic equipment
should not be mixed with general
household waste. Please dispose in
accordance with local regulations.
Product Specifications
| Brand: | Universal Audio |
| Category: | Microphone |
| Model: | Standard SD-7 |
