Page 1/48
www.tritontools.com
Precision Power Saw 235mm / 9 ¼"
TSA 001
Operating and
Safety Instructions
Bedienings- en
veiligheidsvoorschriften
Instructions d’utilisation et
consignes de sécurité
Gebrauchs- und
Sicherheitsanweisung
Istruzioni Per L’uso E
La Sicurezza
Instrucciones de uso y
de seguridad
2
GB ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authority or
retailer for recycling advice.
Always wear ear, eye and respiratory protection
Conforms to relevant EU legislation
and safety standards
Double insulation
Do not use before viewing and
understanding the full operating
instructions
CONTENTS
Thank you for purchasing this Triton . These instructions contain information necessary product
for safe and effective operation of this product.
Please read this manual to make sure you get the full benefit of its unique design.
Keep this manual close to hand and ensure all users of this have read and fully understand the instructionsproduct .
Contents / Specifications
Specifications 2
Symbols 2
Know your product 3
Safety 4
Assembly 5
Operation 7
Maintenance 8
Guarantee 9
Part no: TSA001
Voltage: EU - 220V - 240V AC, 50/60Hz, 9.1A
JP - 100V - 110V AC, 50/60Hz, 15A
USA - 120V AC, 60Hz, 14A
Speed: EU - 4100min-1
JP - 3900min-1
USA - 3900min-1
Blade size: 235mm / 9¼"
Blade arbor: 16mm or 25mm / 5⁄ " "8 or 1
Bevel adjustment: 0˚ – 45˚
Cut depth: 90˚ – 84mm / 3.3"
45˚ – 61mm / 2.4"
Insulation class: Double insulated
Net weight: 8.0kg / 17.6lbs
Protect your hearing
Always use proper hearing protection when tool noise exceeds 80dB.
SPECIFICATIONS
SYMBOLS
3
GB
Parts List
KNOW YOUR PRODUCT
1. Dust Port
2. Rear Pivot Lock
3. Aluminium Baseplate
4. TCT Blade
5. Ripping Guide
6. Inner & Outer Sighting Notches
7. Blade Angle Trimmer
8. Bevel Calibrations
9. Bevel detent latch
10. Motor
11. Onboard Spanner
12. Fence Guide
13. Saw Alignment Slot
14. Micro Adjustment Knob
15. Height Adjustment Assembly
16. Spindle Lock
1
6
3
4
10
8
2
7
5
11
12 13
14
16
15
9
