Owner’s Manual
USB 3.1 Gen 1 USB-C
Docking Station - Silver
Model: U442-DOCK4-S
USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum.
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
All trademarks and registered trademarks are the property of their respective owners.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Español 9 • Français 17 • Русский 25
21-03-270-933DBD.indb 1
21-03-270-933DBD.indb 1
21-03-270-933DBD.indb 1
21-03-270-933DBD.indb 1
21-03-270-933DBD.indb 1 7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
2
Product Features
System Requirements
• Supports USB DisplayPort Alternate Mode for connecting a VGA, DisplayPort or HDMI
monitor via a USB-C or Thunderbolt 3 port
• Supports the connection of three monitors at the same time through DisplayPort
MST Mode*
• Supports connection of DVI monitor via HDMI to DVI adapter (see )Optional Accessories
• Supports connection of Mini DisplayPort monitor via DP to Mini DisplayPort adapter
(see )Optional Accessories
•
DisplayPort and HDMI ports support 4K x 2K video resolutions up to 3840 x 2160 @ 30 Hz
• VGA port supports video resolutions up to 1920 x 1200, including 1080p @ 60 Hz
• Ethernet port supports true 10/100/1000 Mbps network speeds
• USB-A Hub ports support data transfer rates up to 5 Gbps
• Dedicated 5V/1.5A USB port provides fast charging power to mobile devices
• USB-C port supports both data and PD Charging; supports power input up to
20V 5A (100W)
• 4 USB-A and 1 Type-C ports share a max 12W (5V 2.4A) of power
• 3.5 mm Mini Stereo jack on front of unit for connection of speaker and microphone
• 3.5 mm Mini Stereo jack on back of unit for connection of speaker
• Automatically resumes operation from hibernation and suspend mode
• IEEE 802.3az (Energy Efficient Ethernet) compliant
• Supports full duplex and half duplex operations
• Supports IPv4 and IPv6 pack Checksum Offload Engine (COE) to reduce CPU loading
• Supports Wake-on LAN
• Plug-and-play; no software or drivers required
* See section for detailsMulti-Monitor Requirements
• Computer with USB-C or Thunderbolt 3 port that supports USB DisplayPort
Alternate Mode
• DisplayPort, Mini DisplayPort,* VGA, DVI* or HDMI monitor
• Ethernet Network with speeds up to 10/100/1000 Mbps
*Requires an adapter. See Optional Accessories
21-03-270-933DBD.indb 2
21-03-270-933DBD.indb 2
21-03-270-933DBD.indb 2
21-03-270-933DBD.indb 2
21-03-270-933DBD.indb 2 7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
3
Optional Accessories
Package Includes
• N201-Series Cat6 Gigabit Snagless Patch Cables
• P502-Series High-Resolution VGA Cables
• P566-Seires HDMI to DVI Adapter Cables
• P568-Series High-Speed HDMI Cables
• P580-Series DisplayPort Cables
• P583-Series mDP to DP Adapter Cables
• U322-Series USB 3.0 A/B Device Cables
• U326-Series USB 3.0 Micro-B Device Cables
• U420-003-G2-5A USB 3.1 Gen 2 USB-C M/M Cable (3 ft.)
• U442-DOCK4-S
• USB Type-C Cable, M/M (2.6 ft.)
• External Power Supply (Input: 100-240V, 50/60 Hz, 1.8A; Max Output: 20V 3.6A)
• Owner’s Manual
21-03-270-933DBD.indb 3
21-03-270-933DBD.indb 3
21-03-270-933DBD.indb 3
21-03-270-933DBD.indb 3
21-03-270-933DBD.indb 3 7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
7/27/2021 10:08:00 AM
