Owner’s Manual
SmartRack® NEMA-3R
Wall-Mount Heavy Duty
Cabinet
General-Use Industrial Control
Models: SRN3RG12UHD, SRN3RG18UHD
(Series Number: AG-0606)
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR®
surge protector in our monthly drawing!
tripplite.com/warranty
Table of Contents
1. Important Safety Instructions 2
2. Overview 2
3. Feature Identification 3
4. Enclosure Installation 4
4.1 Preparation 4
4.2 Unpacking 4
4.3 Ground Connection 5
5. Enclosure Configuration 5
5.1 Door Locks 5
5.2 Cable Access and Management 5
5.3 Mounting Rails 6
5.4 Adjusting Mounting Rail Depth 6
6. Wall Mounting the Enclosure 7
7. Equipment Installation 9
8. Specifications 9
8.1 Unit Dimensions 9
8.2 Package Dimensions 9
9. Storage and Service 10
10. Warranty and Product Registration 10
Español 11
Francais 21
2
• The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it
unassisted. Use a mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container.
• Do not place any object on the enclosure, especially containers of liquid, and do not attempt to stack the enclosures.
• Inspect the shipping container and the enclosure for shipping damage. Do not use the enclosure if it is damaged.
• Leave the enclosure in the shipping container until it has been moved as close to the final installation location as possible.
• Leave adequate space at the front, rear, top and bottom of the enclosure for proper ventilation. Do not block, cover or insert
objects into the external ventilation openings of the enclosure.
• For permanent wall mounting, be sure to securely fasten the enclosure to the building structure before operation.
• Use caution when cutting packing materials. The enclosure could be scratched, causing damage not covered by the
warranty.
• Save all packing materials for later use. Repacking and shipping the enclosure without the original packing materials may
cause product damage that will void the warranty.
• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the
failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.
• This enclosure supports a maximum Conduit Trade Size 2 with a 2.5 inch hole.
• Use only NEMA-3R (or higher) rated conduit/fittings to maintain the enclosure’s environmental protection rating.
Side-mount, static, heavy-duty, wall-mounted NEMA 3R enclosures accommodate all standard 19-inch rack-mount
equipment, regardless of vendor, and ship fully assembled for quick and easy deployment. They have a NEMA 3R rating for
protection against falling dirt, rain, sleet, snow, windblown dust, splashing water, hose-directed water and external formation
of ice. These adaptable, heavy-duty cabinets come in two heights and have variable mounting depths, making them ideal for
servers. They include removable, lockable front and rear doors.
1. Important Safety Instructions
2. Overview
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that must be followed during the installation and operation of the
product described in this manual. Failure to comply may invalidate the warranty and cause property damage or
personal injury.
3
3. Feature Identification
Model SRN3RG12UHD is shown. The SRN3RG18UHD has similar features, with the only differences being rack height.
1 Rear Door
2 Front Door
3 Horizontal Rails
4 Vertical Mounting Rails
5 Internal Fans
6 Removable Cable Access Hole Covers
7 Fan Cover Panel
2
6
3
4
1
5
7
