Tangent Spectrum Square Manual
Read below 📖 the manual in Italian for Tangent Spectrum Square (71 pages) in the Speaker category. This guide has been helpful for 7 people and has been rated 4.5 stars on average by 2 users
Page 1/71
spectrum square
Enceinte stereo Bluetooth
Manuel utilisateur
FR
2
Spectrum Square
Caractéristiques
• Modèle : Tangent Spectrum Square
• Puissance totale : 60W RMS / 100W max – Quadri-Amplification
• Bluetooth : 5.0 - TWS (True Wireless Stereo)
• Filtre répartiteur : Actif (Linkwitz Riley 24dB/oct) - DSP
• Grave - médiums : 2 x 110 mm
• Tweeters dôme soie : 2 x 19 mm
• Gamme de fréquence : 50 – 22 000 Hz ± 3 dB
• Charge : Bass-Reflex – 1 évent par voie
• Finition : Coffret rigide en bois MDF
• Entrée Aux : 2V RMS
• Alimentation externe : 21V – 2A
• Dimensions : L330 x H330 x P200 mm
• Poids net : 5.80 kg
• SKU : TANSPECSQU
• EAN : 5703959120885
Contenu
Accessoires 3
Caractéristiques 2
Panneau avant de contrôle 3
Panneau arrière de connexions 4
Procédure de Connexion Bluetooth 5
Configurer le Mode TWS (True Wireless Stereo) 5
Mode loudness 5
Retirer l’enceinte de l’étagère 6
Consignes de Sécurité Importantes 6
Avertissement 7
Propriété Intellectuelle 7
Garantie 7
Contact et retour d’information 8
3
FR
Spectrum Square
Panneau avant de contrôle
Mise en fonction (1) / arrêt (0)
1
Led relative aux sources :
• Blanc fixe : entrée Aux
• Bleu clignotant : appairage Bluetooth
• Bleu fixe : mode Bluetooth
• Jaune clignotant : appairage TWS (True Wireless Stereo)
• Jaune fixe : mode TWS entre les deux enceintes
2
Sélecteur de source (simple pression) :
La source par défaut est le mode bluetooth. A chaque mise sous tension, l’enceinte
se synchronise instantanément en mode bluetooth.
3
Sélecteur de modes sonores (simple pression) : Neutral (par défaut) & Loudness
Lorsque vous appuyez sur le pictogramme de la note de musique, la LED blanche
clignotera deux fois pour indiquer que le mode EQ est en mode Neutre.
Si vous appuyez à nouveau sur le pictogramme de la note de musique, la LED
blanche clignotera six fois pour indiquer que le mode EQ est en mode Loudness.
4
Contrôle du volume :
• Simple pression - réglage du volume d’un palier.
• Appuis prolongés - réglage du volume par 16 paliers
Pendant ces actions, la LED verte effectue des clignotements pour indiquer l’opé-
ration.
L’enceinte conserve en mémoire le niveau de volume précédemment réglé. Il est
donc recommandé de réduire le volume avant de l’éteindre.
5
Accessoires
• Patins en caoutchouc
• Alimentation externe
• Câble mini-jack stéréo 3,5 mm
• Grille supplémentaire
