Summit ASDW2412 Manual
Summit
Wine climate cabinet
ASDW2412
Read below 📖 the manual in Italian for Summit ASDW2412 (33 pages) in the Wine climate cabinet category. This guide has been helpful for 2 people and has been rated 4.5 stars on average by 2 users
Page 1/33
WINE and BEVERAGE COOLER
MODELS:
Beverage Coolers:
ASDG1521
ASDG2411
SDHG1533
SDHG2443
CL156BV
DBGR1563ASD
DBGR2464ASD
DBGR1565SD
DBGR2466SD
DBGR1569
CL181WBV
CL24BV1
ALBV15
AL57GPNR
DBGR1834
DBGR2435
DBGR1562ASD
DBGR2461ADA
Wine Coolers:
ASDW1522
ASDW2412
SDHW1532
SDHW2442
CL155WC1
DBWC1542ASD
DBWC2443ASD
DBWC1544SD
DBWC2445SD
DBWC1549
CL18WC
CL244WC2
ALWC15
DBWC1846
DBWC2447
DBWC1541ADA
Wine/Beverage Coolers:
ALFD24WBV
CLFD243WBV
DBFD2495ADA
DBFD2496
User Manual
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Felix Storch, Inc.
An ISO 9001:2015 registered company
770 Garrison Ave
Bronx, New York 10474
www.summitappliance.com
Write Serial Nos. (on lower left corner of
inside cabinet) here:
2
TABLE OF CONTENTS
Appliance Safety 3
Important Safeguards 3-5
Disposal 5
Location of Parts 6-8
Installation Instructions 9-14
Before Using your Appliance 9
Installation of your Appliance 9- 11
Electrical Connection -11 12
Reversing the Door Swing of your Appliance 12
Adjusting the Kick Plate 13
Installing the Stainless Steel Handle 13
Full Overlay Panel Installation Instructions 14-16
Operating your Appliance 16-26
Recommended Temperature Setting for Wine Cellars 16
Control Panel 16-22
Settings Mode 22-23
Interior Light 23
Sabbath Mode 23
Temperature Memory Function 23
Temperature Alarm/Door Alarm 23- 24
Dynamic Cooling and Silent Mode 24
Door Lock 24
Shelves 24-25
Defrosting 25
Storage 26
Care and Maintenance 27
Cleaning your Appliance 27
Power Failure 27
Vacations 27
Moving your Appliance 27
Energy-Saving Tips 27
Troubleshooting 28-29
Limited Warranty 32
3
APPLIANCE SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. The symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words "DANGER" or "WARNING ".
DANGER means that failure to heed this safety
statement may result in severe personal injury or
death.
WARNING means that failure to heed this safety
statement may result in extensive product damage,
serious personal injury, or death.
All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury,
and let you know what can happen if the instructions are not followed.
IMPORTANT SAFEGUARDS
Before the appliance is used, it must be properly positioned and installed as
described in this manual so read the manual carefully. To reduce the risk of re, ,
electrical shock or injury when using the appliance, follow basic precautions ,
including the following:
• Plug into a grounded 3-prong outlet, do not remove the grounding prong, do not use an adapter, and
do not use an extension cord.
• Replace all panels before operating.
• is recommended that a separate circuit serving only your appliance be provided. Use receptacles It
that cannot be turned o by a switch or pull chain.
• Never clean appliance parts with flammable uids. These fumes can create a re hazard WARNING:
or explosion. And do not store or use gasoline or other ammable vapors and liquids or explosive
substances such as aerosol cans with a ammable propellant in this appliance or in the vicinity of this
or any other appliance. The fumes can create a re hazard or explosion.
• not connect or disconnect the electric plug when your hands are wet. Do
• Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in
electrical shock or death.
• not attempt to repair or replace any part of your appliance unless it is specically recommended in Do
this manual. All other servicing should be referred to a qualied technician.
A3 Warning: Risk of Fire / Flammable Materials. R600a
• This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is
environmentally friendly, but ammable. It does not damage the ozone layer, nor does it increase the
greenhouse eect. Care must be taken during transportation and setting up of the appliance that no
parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.
Product Specifications
| Brand: | Summit |
| Category: | Wine climate cabinet |
| Model: | ASDW2412 |
