24" UNDERCOUNTER REFRIGERATOR - PANEL READY

U C - 2 4 R

FEATURES

Compact unit fits in anywhere

Easy-access touch control panel

Temperature range from 34⁰F to 45⁰F

Bright interior lighting

Clear utility bin for smaller items

Two-liter bottle storage in door

Spill-proof glass shelves for easy clean-ups

ACCESSORIES

Dual Installation Kit

Stainless Steel Door Panel with Pro Handle

Stainless Steel Door Panel with Tubular Handle

Undercounter Black Dual Kickplate

Undercounter Door Lock Kit

Undercounter Dual Lock Kit

Undercounter Silver Dual Kickplate

Undercounter Silver Kickplate

Stainless Steel Pro Handles

Stainless Steel Tubular Handles

Accessories are available through an authorized dealer.

For local dealer information, visit subzero-wolf.com/locator.

HANDLE ACCESSORIES

PRODUCT DETAILS

REFRIGERATOR

• 1 storage bin

• 3 glass shelves (2 adjustable; 1 stationary)

• 2 door bins

Specifications are subject to change without notice. This information was generated on May 11, 2024. Verify specifications prior to finalizing your cabinetry/enclosures.

24" UNDERCOUNTER REFRIGERATOR - PANEL READY

PRODUCT SPE CIFI CATIONS

Model UC-24R

Dimensions 23 7/8"W x 34"H x 24"D

Refrigerator Capacity 5.7 cu. ft.

Door Clearance 25 3/8"

Weight 153 lbs

Electrical Supply 115 VAC, 60 Hz

Electrical Service 15 amp dedicated circuit

ELECTRICAL

NOTE: Dimensions in parenthesis are in millimeters unless otherwise specified

INTERIOR VIEW

This illustration is intended for interior reference only and may not represent the exterior

of the model being specified.

DIME NSI ONS

STANDARD INSTALLATION

24"

(610)

OPENING WIDTH

(876)

OPENING

HEIGHT

TOP VIEW

SIDE VIEW

FRONT VIEW

NOTE:

(89)

finished returns will be visible and should be finished to match cabi

(

19)

TYPICAL

FRAMED

CABINETRY

24"

(610)

FILLER

(89)

FINISHED

RETURN

FRAMELESS

CABINETRY

24"

(610)

(

19)

TYPICAL

(89)

FINISHED

RETURN

24"

(610)

OPENING

DEPTH
