Page 1/53
4-599-596-15 (1)
Baseband Processor
Unit
Operating Instructions
Before operating the unit, please read this manual thoroughly
and retain it for future reference.
BPU4800
© 2016 Sony Corporation
2
Table of Contents
Overview.................................................................... 3
System Configuration ......................................................4
Name and Function of Parts .................................... 6
Front Panel ......................................................................6
Rear Panel ......................................................................7
Connection and Setup............................................ 10
4K System Connection ..................................................10
Extension Mode (HD System) Connection ....................11
HFR Data Transfer Connection .....................................12
Relationship between Operation Mode and Output
Slots ...........................................................................12
About Recording Times .................................................14
Status Display ......................................................... 16
Displaying the Status Screen ........................................16
Status Display Screen ...................................................16
BPU Menu Settings................................................. 16
Changing Settings using the Menu ...............................16
Menu Tree .....................................................................18
Menu List .......................................................................19
Web Menu Settings................................................. 24
Displaying the Web Menu .............................................24
Configuring the Network ................................................24
Setting the System and Boards .....................................24
Web Menu Organization ...............................................24
Home Screen ................................................................25
Status Screen ................................................................28
System Screen ..............................................................28
Port Screen ...................................................................35
File Screen ....................................................................39
Storage Screen .............................................................40
File Operations via FTP ................................................43
Appendix ................................................................. 47
Precautions ...................................................................47
Troubleshooting ..................................................... 47
Salvaging Memory when Recording Ends
Abnormally .................................................................47
Error Messages .............................................................48
Warning Messages .......................................................49
Displaying the Error Log ................................................51
Specifications ......................................................... 52
3
Overview
The BPU4800 Baseband Processor Unit connects to an
HDC4800 Color Camera, using an optical fiber cable, and
performs signal processing and video output of the signal
from the camera.
The unit is equipped with high-speed, large-capacity storage
for recording and playback of signals from a camera.
• When the 4K HFR option1) is installed, recording 4K
(3840×2160) at 8×/4× speed is supported.
• When the HD HFR option2) is installed, recording HD
(1920×1080) at 16×/8× speed is supported.
• When the option memory board3) is installed,
recording/playback of up to four hours of 4K at 8× speed is
supported.
1) SZC-4008 4K HFR software
2) SZC-2016 HD HFR software
3) SKC-MEM4 extension memory board
It supports the Share Play function for file sharing when
connected to a PWS-4500 Production Video Server via a
network connection, allowing you to play back BPU4800
content from the PWS-4500. It supports the high dynamic
range and wide color gamut required for high-definition video
production. It also supports transmission over IP for high
affinity with network infrastructures.
The unit can be connected to an HDCU2000-series Camera
Control Unit for conventional camera system operation,
supplying power to the camera and transferring various
signals (such as intercom, tally, prompter, and audio).
