Part Number 7120501 / ENGLISH REV B - 09/2023
IR61130, IR61131, IR61132
SAVE THIS MANUAL FOR FUTURE REFERENCE
USE AND CARE MANUAL
PRESSURE WASHER
READ THIS MANUAL CAREFULLY BEFORE OPERATION
Failure to follow the instructions and safety precautions in this manual can result
in property damage, serious injury and/or death.
NOTE: Photographs and line drawings used in this manual are for reference only and may not
represent your specic model.
If your pressure washer is not working or if there are parts missing or broken, please DO NOT
RETURN IT TO THE PLACE OF PURCHASE. Contact our Customer Service Department by calling
1-877-362-4271 or emailing cservice@fna-group.com
IR61130
IR61131
IR61132
Page II
THIS PAGE WAS INTENTIONALLY LEFT BLANK
●All information in this publication was based on the latest product information available at
the time of printing. The FNA Group reserves the right to update, change, and/ improve
the product and this document at any time, without notice, and without incurring any
obligation.
● This manual may cover more than one machine. The pictures and gures in the manual
should be used for reference only. There may be dierences between your product and
the pictures, drawings, and diagrams in this manual.
DISCLAIMERS
Page 1
SAVE THIS MANUAL FOR FUTURE USE
Write down the model number, serial number, and purchase date of this product in the spaces
provided below then keep this manual with the purchase receipt(s) for future reference.
Keep this manual for future reference. This manual should be considered a permanent part
of the product and stay with it. This manual should be available to anyone operating the
product(s) it covers. This manual should remain with the product(s) it covers if sold to a new
owner. If the manual becomes damaged, lost, or otherwise unusable, you may download
a new copy from the product pages at www.simpsoncleaning.com or contact customer
support by calling 1-877-362-4271.
Model Number:
Serial Number:
Purchase Date:
Page 2
TABLE OF CONTENTS
Adding the Pump Breather Cap 7
ASSEMBLY 7
DISCLAIMERS 6
PERSONAL PROTECTIVE EQUIPMENT
6
Hazard Alert Symbols 4
Additional Instructions 4
Read this Manual Before Operating 4
4SAFETY INSTRUCTIONS
Organize Accessories
Assemble the Spray Gun
8
8
COMPONENT LOCATION 9
CONNECTING HOSES 11
PURGING AIR FROM THE PUMP 12
NOZZLES 13
Nozzle Installation 13
Nozzle Selection 13
USING CHEMICALS 18
OPERATING CHECKLIST 14
Operating Conditions
Location 14
14
STARTING THE PRESSURE WASHER 15
TURNING OFF PRESSURE WASHER
19
UNPACKING 7
9
10
IR61130, IR61131
IR61132
Page 3
Pressure Washing 20
Preparation 20
Terms 20
20OPERATION TIPS
21TROUBLESHOOTING
22MAINTENANCE
Maintenance
Cleaning the Pressure Washer
22
22
Connections
Nozzle Cleaning
22
23
Water Inlet Filter
Pump Maintenance
23
24
24
STORING THE PRESSURE WASHER
25USING SIMPSON® PUMP GUARD
Adjusting Pressure 20
26WARRANTY
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
DANGER:
DANGER:
DANGER:
DANGER:
DANGER:
CAUTION:
CAUTION:
CAUTION:
CAUTION:
CAUTION:
Page 4
This manual contains important safety information and instructions. Do not operate
this product until you have read, and completely understand all safety, operation, and
maintenance instructions listed in this manual. Failure to follow the information contained
in this manual will result in property damage, injury, and/or death.
NOTE: The warnings and precautions discussed in this manual cannot cover all conditions
and situations that may occur. The operator must understand awareness and caution are
factors which cannot be built into this product and so must be exercised by the operator.
READ THIS MANUAL BEFORE OPERATING
ADDITIONAL INSTRUCTIONS
Be sure to understand the safety symbols and denitions listed below. Each symbol
contains one of four words: DANGER WARNING CAUTION, , , NOTICE, indicating
dierent levels of hazard severity. These symbols are used throughout this manual and
are followed information about a specic hazard, the consequences of the hazard, and
instructions on how to avoid the hazard. Failure to heed these symbols and follow the
instructions provided with them will result in property damage, injury, and/or death.
HAZARD ALERT SYMBOLS
Indicates an imminently dangerous situation, which if not
avoided, will result in property damage, serious injury, and/
or death.
Indicates a potentially hazardous situation, which if not
avoided, could result in property damage, serious injury, and/
or death.
Indicates a hazardous situation, which if not avoided, could
result in property damage and/or minor to moderate injury.
Indicates information considered important, but not directly
hazard related.
SAFETY INSTRUCTIONS
Along with this manual, be sure to read any additional instructions provided both on and
with the product, attached equipment, accessories, and the motor powering the product.
Pay careful attention to all additional safety rules and instructions on proper startup,
operation, and shutdown procedures. Always use any recommended protective apparel
that may be needed to operate the equipment safely.
NOTICE
Page 5
Special consideration needs to be made to the safety of not just the operator of the
pressure washer, but also people who may be adjacent to the area being cleaned.
The best way to warn unsuspecting individuals is with signage and barriers.
Barriers can be as simple as plastic trac cones or barricades to using barrier belts
around the area being cleaned. Remember, pressure washing can dislodge weak or
broken pavement turning it into projectiles that may injure others. Keeping people
clear of the area is the best way to avoid injury.
Wet pavement can be slippery to unsuspecting individuals causing injury from slips
and falls. High-pressure and low-pressure hoses can be trip hazards. Segregating
the area and placing appropriate signage can reduce injury.
Barrier examples
KEEP OUT
HIGH
PRESSURE
WASHING
IN
PROGRESS
Sign examples
When pressure washing in public areas, signs should be posted
that indicate to stay clear of the area as high-pressure washing
is being performed. Also, signs should be posted that the
surface may be slippery and trip hazards may be present.
SLIP / TRIP HAZARDS
CAUTION:
CAUTION:
CAUTION:
CAUTION:
CAUTION:
Hoses may pose a tripping
hazard that can cause injuries
resulting from a fall.
CAUTION
TRIPPING HAZARD
Page 6
This product can expose you to chemicals which are known to the state of California
to cause cancer, birth defects, or other reproductive harm. For more information on
California Proposition 65, go to www.P65Warnings.ca.gov.
CALIFORNIA PROPOSITION 65 WARNING
●All information in this publication was based on the latest product information available at
the time of printing. The FNA Group reserves the right to update, change, and/ improve
the product and this document at any time, without notice, and without incurring any
obligation.
● This manual may cover more than one machine. The pictures and gures in the manual
should be used for reference only. There may be dierences between your product and
the pictures, drawings, and diagrams in this manual.
DISCLAIMERS
PERSONAL PROTECTIVE EQUIPMENT (PPE)
It is important to understand what personal protective equipment (PPE) should be
utilized when using your pressure washer. Below is a list of PPE items that should
be utilized at all times when using the pressure washer.
Hearing - Ear plugs or mus to protect your hearing.
Vision - Safety goggles to protect your eyes.
Clothing - Long pants to protected your legs from ying debris.
Shoes - Shoes that fully cover your feet to protect against debris and over spray.
NOTICE
This appliance is not intended to be used by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Adding the pump breather cap (if applicable)
A RED shipping plug is in the pump that must be replaced with a BLACK breather cap.
The plug is easy to replace with the following steps:
1. Using a bladed screw driver, remove the RED shipping plug from the top of the pump.
2. Hand thread the BLACK breather cap into the pump.
3. Snug the cap with your ngers.
RED shipping plug
BLACK breather cap
Page 7
UNPACKING
ASSEMBLY
Follow the steps outlined in this section to unpack and assemble your pressure washer.
If you have any questions regarding the unpacking or assembly of your pressure washer,
please have your model number and serial number ready, then contact customer support at
1-877-362-4271 or email cservice@fna-group.com.
1. Place the shipping carton on a solid, at surface.
2. Carefully cut the top of the carton open.
3. Carefully cut each corner of the carton from top to bottom.
4. Lay each side of the carton at on the ground.
5. Remove the contents of the carton.
WARNING!
The threads on the lance and gun coupler can be easily cross threaded resulting
in an improper assembly. An improper assembly of the gun and lance can result in personal
injury. Do not use if the threads on the gun coupler and or lance are cross
threaded.
Hand thread the lance clockwise
into the gun. Be careful not to
cross-thread the gun and lance.
Using an adjustable wrench,
tighten the lance by placing the
wrench on the ats of the nozzle
quick-connector.
Page 8
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
Attempting to use the pressure washer incorrectly can result in motor and/or pressure
washer damage, and may cause serious injury or death. To avoid these hazards, be sure
to read, understand, and follow the steps outlined in the OPERATING CHECKLIST section
of the owner’s manual and follow all the guidelines for proper use of the pressure washer.
OPERATING CHECKLIST
Assemble the spray gun
Organize accessories
Place the spray gun and lance
assembly into the holder on
the dashboard.
1.
Push the nozzles into the
rubber grommets on the dash-
board. Note: the dashboard
label indicates correct nozzle
placement.
2.
Hang the high-pressure hose
on the holder.
3.
1
2
3
Page 9
COMPONENT LOCATION
1 2 3 4 5 6 7 8 9 10
11 12 13 14 15 16 17 18
10. Spray wand quick connector
9. Electric motor
8. ON/OFF switch
7. Pump
6. Unloader control knob
5. Spray gun holder
4. Spray gun
3. Spray gun trigger lock
2. Spray gun trigger
1. Nozzle holders
18. Wheel
17. NEMA 6-30 male power supply plug
16. Thermal relief valve
15.
Ground Fault Circuit Interrupter (GFCI)
14. Garden hose coupler and lter
13. High-pressure pump outlet
12. Hose hanger
11. High-pressure hose
IR61130
IR61131
Page 10
1 2 3 4 5 6 7 8 9 10 11
12 13 14 15 16 17 18
10. Electric motor
9. ON/OFF pushbuttons
8. Pump
7. Unloader control knob
6. Thermal relief valve
5. Spray gun holder
4. Spray gun
3. Spray gun trigger lock
2. Spray gun trigger
1. Nozzle holders
18. NEMA 6-50 male power supply plug
17. Wheel
16.
Ground Fault Circuit Interrupter (GFCI)
15. Garden hose coupler and lter
14. High-pressure pump outlet
13. Hose hanger
12. High-pressure hose
11. Spray wand quick connector
IR61132
Page 11
Before connecting a water supply hose, be sure the water supply is capable of providing an
uninterrupted source of clean, cold water at a minimum rate of 5 gallons per minute (GPM)
and 20 pounds per square inch (PSI) of pressure. Once a proper water supply is secured,
follow the instructions below to connect both the water supply and high-pressure hoses to
the pressure washer.
CONNECTING HOSES
Verify the inlet screen is free of
any dirt or debris and is in place
with the convex side facing out.
1.
Turn on the water supply and
run for 30 seconds to purge any
debris from the supply hose.
Then, turn o the water supply
and thread the water supply hose
into the pump inlet.
2.
While pulling back on the pump
outlet collar, insert the hose
connector then release the collar.
Gently tug on the hose to make
sure it is locked.
3.
While pulling back on the hose outlet collar, insert the gun connector then
release the collar. Gently tug on the hose to make sure it is locked.
4.
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
NOTICE
Page 12
A pressure washer pump is designed to operate with water owing through it. Water
lubricates and cools the internal components of the pump. Running a pressure washer pump
without water will severely damage the pump seals and other internal components. Damage
caused by running a pressure washer pump without water is not covered under warranty.
Be sure to follow the instructions below to correctly purge the air from your pressure washer
pump before starting the engine.
PURGING AIR FROM THE PUMP
Running a pressure washer pump without water will severely damage the pump seals
and other internal components. To avoid this hazard, make sure your water supply is
uninterrupted and at least 5 GPM at 20 PSI, and always purge the air your pressure
washer pump before starting the engine.
PUMP PURGING
The high pressures created by a pressure washer can cause uid injection injuries,
severe lacerations, amputations, and / or death. To avoid these hazards, always aim
the spray gun and lance in a safe direction when using the pressure washer and never
attempt to touch a leak in a high-pressure hose or tting.
INJECTION INJURY
1. Connect all the hoses by following the steps outlined in the CONNECTING HOSES
section of this manual then turn on the cold water source.
2. Aim the spray gun in a safe direction then squeeze and hold the trigger for at least 30
seconds or until the water runs steady and all the air is purged from the pump and hoses.
3. Check hoses and connections for leaks. If leaks are found, turn o the machine, aim
the spray gun in a safe direction and squeeze the trigger to relieve any built up pressure
in the system. Never attempt to touch a leak in a high-pressure hose or tting. Never
attempt to repair a high-pressure hose.
Engage the trigger lock.4.
Page 14
OPERATING CHECKLIST
Location
Operating Conditions
Place the pressure washer on a level surface outside. Never use an extension cord with
the electric pressure washer. If the power supply cord will not reach a receptacle, move the
pressure washer closer to the receptacle.
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
Failure to inspect this product before use could create a hazardous situation resulting
in product damage, serious injury, and/or death. To avoid these hazards, inspect the
pressure washer before each use. Check for loose or damaged parts, signs of oil leaks,
missing guards, plugged cooling vents, or any other condition that may aect proper
operation. Repair or replace all damaged or defective parts and keep all safety guards in
place and in proper working order before using the pressure washer.
INSPECT BEFORE OPERATING
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
Untrained adults and children can be seriously injured or killed if allowed to incorrectly
operate or play with running pressure washer. To avoid these hazards, be sure anyone
operating the pressure washer receives proper instructions, understands safe operation,
and has read the owner’s manual before operating this product. Do not let children
operate the pressure washer without parental supervision. Keep children and pets away
from the pressure washer while it is running. Always turn o the pressure washer before
leaving the area.
UNTRAINED OPERATION
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
Spray can splash back or propel objects. Always wear properly rated eye protection
such as safety goggles or face shield while spraying. (Safety glasses do not provide full
protection).
RISK OF EYE INJURY
Know how to stop the product and bleed pressures quickly. Be throughly familiar with the
controls. Stay alert - watch what you are doing. Do not overreach or stand on unstable
support. Keep good footing and balance at all times. Do not operate the product when
fatigued or under the inuence of alcohol or drugs. Keep operating area clear of all persons.
Before each use, check for loose or damaged parts, leaks, and/or any other condition
that may aect proper operation. Repair or replace all damaged and/or defective parts
immediately. Always keep all safety guards in place and in proper working order. For safety
reasons, the manufacturer recommends all maintenance and repairs be performed by an
authorized service center.
Before using the pressure washer, remove any excessive dirt and debris from the cooling
vents of the motor. Always operate the pressure washer on a level surface and never move
or tip the pressure washer while operating. Use the pressure washer only for its intended
purpose. If you have questions about the proper use of your pressure washer, please
contact customer support at 1-877-362-4271 or cservice@fna-group.com.
Product Specifications
| Brand: | Simpson |
| Category: | High pressure cleaner |
| Model: | ALIR2535012B |
Do you need help?
If you need help with Simpson ALIR2535012B, ask a question below and other users will answer you
High pressure cleaner Simpson User Manuals
24 October 2024
24 October 2024
24 October 2024
24 October 2024
15 October 2024
14 October 2024
High pressure cleaner User Manuals
- High pressure cleaner Bosch
- High pressure cleaner DeWalt
- High pressure cleaner Cecotec
- High pressure cleaner SereneLife
- High pressure cleaner Comet
- High pressure cleaner Ryobi
- High pressure cleaner Generac
- High pressure cleaner Einhell
- High pressure cleaner Anova
- High pressure cleaner Vonroc
- High pressure cleaner Worx
- High pressure cleaner Karcher
- High pressure cleaner Yellow Garden Line
- High pressure cleaner CMI
- High pressure cleaner Jet-USA
- High pressure cleaner MacAllister
Latest High pressure cleaner User Manuals
26 October 2024
26 October 2024
26 October 2024
26 October 2024
26 October 2024
26 October 2024
26 October 2024
21 October 2024
20 October 2024
19 October 2024
