Page 1/41
OPERATORâS MANUAL
MANUEL DâUTILISATION
MANUAL DEL OPERADOR
18 VOLT POLE SAW
SCIE DE MANCHE 18 V
SIERRA DE PĂRTIGA DE 18 V
P2501
WARNING: To reduce the risk
of injury, the user must read and
understand the operatorâs manual
before using this product.
TABLE OF CONTENTS
îImportant Safety Instructions 2 .............
îSpeciïŹc Safety Rules 3-4 .....................
îSymbols 4-5 ..........................................
îFeatures 6 ..............................................
îAssembly 6-7 ........................................
îOperation 7-9 ........................................
îMaintenance 19-11 ...............................
îTroubleshooting 12 ................................
îParts Ordering/Service Back Page .......
AVERTISSEMENT : Pour
réduire les risques de blessures,
lâutilisateur doit lire et veiller Ă bien
comprendre le manuel dâutilisation
avant dâemployer ce produit.
TABLE DES MATIĂRES
î Instructions importantes
concernant la sécurité........................2
îRĂšgles de sĂ©curitĂ© particuliĂšres 3-4 .....
îSymboles 4-5 ........................................
îCaractĂ©ristiques 6 .................................
îAssemblage 6-7 ....................................
îUtilisation 7-9 ........................................
îEntretien 9-12 .......................................
îDĂ©pannage 12 .......................................
îCommande de piĂšces/
réparation Påge arriÚre ..........................
ADVERTENCIA: Para reducir
el riesgo de lesiones, el usuario
debe leer y comprender el manual
del operador antes de usar este
producto.
ĂNDICE DE CONTENIDO
î Instrucciones de seguridad
importantes 2-3 ....................................
îReglas de seguridad especĂïŹcas 3-4 ...
îSĂmbolos 5-6 ........................................
îCaracterĂsticas....................................6
îArmado 7 ...............................................
îFuncionamiento 8-9 ..............................
îMantenimiento 10-12 ............................
îSoluciĂłn de problemas 13 ....................
îPedidos de piezas/
servicio PĂĄg. posterior ..........................
SAVE THIS MANUAL FOR
FUTURE REFERENCE
CONSERVER CE MANUEL
POUR FUTURE RĂFĂRENCE
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS
i
Fig. 1
See this fold-out section for all of the ïŹgures referenced
in the operatorâs manual.
Consulter lâencart Ă volets aïŹn dâexaminer toutes les ïŹgures
mentionnĂ©es dans le manuel dâutilisation.
Consulte esta secciĂłn desplegable para ver todas las ïŹguras a
las que se hace referencia en el manual del operador.
A - Scabbard (fourreau, funda)
B - Cutting Head Pole (arbre du tĂȘte de coupe,
eje de la cabezal de corte)
C - Intermediate Pole (intermédiaire arbre,
intermedia eje)
D - Quick release shoulder harness (bandouliĂšre
Ă relĂąchement rapide, correa para el hombro
de liberaciĂłn rĂĄpida)
E - Handle Pole (arbre de poignĂše, eje de la
manija)
F - Trigger Lock-out (verrouillage de gĂąchette,
seguro del gatillo)
G - Combination wrench (clé mixte, llave de
combinaciĂłn)
H - Switch trigger (gĂąchette de commutateur,
gatillo interruptor)
H
F
C
A
D
G
E
B
ii
Fig. 2
Fig. 3 Fig. 4
A - Handle pole (arbre de poignĂše, eje de la manija)
B - Collar (colier, casquilo)
C - Socket (douille, enchufe)
D - Intermediate pole (intermédiaire arbre, intermedia eje)
E - Threated base (base taraudé, roscado base)
F - Plug (bouchon, toma-corriente)
G - Cutting head pole (arbre du tĂȘte de coupe, eje de la cabezal de corte)
A
D
E
E
G
B
B
F
C
A
A
B
C
A
B
C
A - Spring clip (agrafe Ă ressort, clip de resorte)
B - Latch (loquet, pestillo)
C - Strap hanger (ïŹxations de sangle, asas para correas)
A - Lock-out button (bouton de verrouillage, botĂłn de bloqueo)
B - Switch trigger (gĂąchette de commutateur, gatillo del interruptor)
C Battery (bloc-piles, paquete de baterĂas)
