Description:
ROBINHOOD SLIDEOUT
Model Number:
RLES6WH, RLES6SS, RLES9WH, RLES9SS
RLES61SS/WH, RLES91SS/WH
Model pictured: RLES6 /SS RLES61SS/WHWH
Issue: 8
Page 2 of 6
Exploded view
Page 3 of 6
Part number
Item
Description
RLES6WH
RLES61WH
RLES 6SS
RLES6 1SS
1
Front Handle 32mm
103774WH
103775SS
2
End Cap 32mm (If manufactured post 31/7/09)
103778WH
103778BL
End Cap 32mm (If manufactured between 8/9/08 and
31/7/09) – confirm colour
103778BL or
103778WH
End Cap 32mm (If manufactured pre 8/9/08)
103778BL
3
Side Fixing Screw and Hollow Dowel Kit (4 pieces)
111053
4
Side plastic kit includes both sides and inner covers (If
manufactured post 31/7/09)
111050
111051
Side plastic kit as above (If manufactured between 8/9/08
and 31/7/09) – confirm colour
111050 or 1110 51
Side plastic kit as above (If manufactured pre 8/9/08)
111051
5
Uppco Motor 3 S –peed
103674
6
PCB for 3 Speed Switch
103593
7
Slider Switches (If manufactured post 31/7/09)
102268WH
102268BL
Slider Switches (If manufactured between 8/9/08 and
31/7/09) confirm colour –
102268WH or
102268BL
Slider Switches (If manufactured pre 8/9/08)
102268BL
8
Door Switch
102686
9
Slider Bracket (If manufactured post 31/7/09)
103358WH
103358 WH
Slider Bracket (If manufactured between 8/9/08 and 31/7/09)
– confirm colour
103358WH or
103358BL
Slider Bracket (If manufactured pre 8/9/08)
103358BL
10
Halogen lamp holder (If manufactured post 21/4/08)
111021
Halogen lamp holder (If manufactured between 24/11/08 and
18/12/08)
111075
Incandescent lamp holder (If manufactured pre 21/4/08)
101104
11
Halogen Lamp (If manufactured post 21/4/08)
111020
Incandescent Lamp (If manufactured pre 21/4/08)
102722
NS
Incandescent lamp diffuser (If manufactured pre 21/4/08)
103125
12
Power Cord
103821
13
Filter Aluminium Mesh 478 x 188
103831
Filter Charcoal 478 x 188 (pack of 2)
14971
14
Finger Guard
103943
15
E-Clip
999084
16
Fan Blade
102283
17
Sliding track (If manufactured post 31/7/09)
114350
Sliding track (If manufactured pre 31/7/09)
102245
18
Filter Clip –(If manufactured pre 21/4/08)
102224BLNZ
Filter Clip –(If manufactured post 21/4/08)
102224WHRH Right Hand &
102224WHLH Left Hand
