Page 1/20
RADF-RID
RADF-CAM
AUTO-
DARKENING
WELDING
HELMET USER
GUIDE OWNERS
MANUAL
RADF-CAM
RADF-RID
V1_05.23
ENGLISH
3
WARNING
• Do not use any welding product without appropriate training.
• These products do not provide any protection from respiratory hazards that may result
from welding processes.
• Arc welding can be hazardous. Protect yourself and others from possible serious injury
or death. Keep children away. Read operating / instruction manual before installing,
operating or servicing this product.
• Never use the auto-darkening lens without the inside and outside lens cover properly
installed. Welding spatter will damage the auto-darkening lens and void the warranty.
Welding helmets do not provide unlimited eye, ear and face protection.
Always wear ANSI Z87.1-2003 compliant safety spectacles in addition to any
welding helmet.
Inspect the auto-lens frequently. Immediately replace any scratched, cracked,
or pitted cover lenses or auto-lenses.
Severe burn injuries may result if these welding helmets are used for heavy-
duty overhead welding applications where there is a potential for falling
molten metal.
Do not attempt to use this welding helmet if there are any cracks, or visible damage to
the structure of the helmet and/or auto-darkening filter.
Before First Use
Inspect the welding helmet for the following:
1. The front and inside cover lenses are secure under all the tabs.
2. Damage to the inner and outer cover lenses (e.g.; cracks, scratches, pitted, welding
spatter).
3. Test your shade cartridge prior to welding by directing the front of the cartridge toward
a bright source of light. Then, using your fingers, rapidly cover and uncover the sensors.
The cartridge should darken momentarily as the sensor is exposed. A torch striker can
also be used.
The welding helmet should be adjusted to ensure it is positioned over the eyes and face
to ensure adequate protection.
Adjust Headgear for Proper Fit
1. Headgear tightness – Push down and rotate the knob located on the back of the
headgear left or right.
2. Distance from helmet to face adjustment - Loosen the tension knob on both sides
and slide forward or back to desired position ensuring equal distance on both sides
of the headgear. Note! Make sure both sides are equally positioned for proper
operation.
3. Head size adjustment - Adjust headgear for proper depth on the head for correct
stability and balance.
4. View angle adjustment - Loosen the tension knob on the right side of the helmet, lift
and reposition the lever forward or backward to the desired position.
Product Specifications
| Brand: | RIDGID |
| Category: | Soldering machine |
| Model: | RADF-CAM |
