Quoizel Tiffany TF3180TVB Manual
Read below 📖 the manual in Italian for Quoizel Tiffany TF3180TVB (1 pages) in the Lamp category. This guide has been helpful for 4 people and has been rated 4.5 stars on average by 2 users
Page 1/1
Please go to for product cleaning tips. Go to the selection.
(2) Medium Base Bulbs 75W Maximum
20-30 minutes
Identify and inspect all parts before beginning installation. Check package content list and diagrams below to be sure all parts are
present. If any parts are missing or damaged, do not attempt to assemble, install, or operate the fixture. Contact customer service for replacement
parts.
www.quoizel.com Care + Maintenance
Bulb Recommended:
Estimated Assembly Time:
Preparation:
Tools Required: Pliers.
Warnings and Cautions
1of1
Assembly Instruction Sheet #IS-TF3180TVB
For Style TF3180TVB
2017 QuoizelInc. ReleasedDate:2017-03-02
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal.
Care of Tiffany Style Shade
A new tiffany lamp shade has an oil film applied to the shade that protects the tiffany shade from scratches during shipment. If the oil applied is
too heavy you can remove the excess oil film with a paper towel. Gently wipe away the excess oil.
For general cleaning of tiffany shades use a gentle lemon oil-based furniture polish applied to a soft cloth and wipe gently.
If a white powder appears on the soldered joints of the tiffany shade this is a normal oxidation process. Use a small amount of lemon oil or
mineral oil applied directly to oxidized areas and the soldered area will return to like new.
A. Thread the Center Column on the bottom
center of the Socket Assembly and hand
tighten until snug.
B. Place the Base, the Lock Washer and
the Spring Washer over the nipple
Finial
x 1
Shade
x 1
Bulb (not
included)
TF3180TVB
NOTE: ALL DIMENSIONS ARE ROUNDED
UP TO THE NEAREST 1/4"
Flat Washer
x 1
Big Knurled
Nut x 1
Check Ring
x 1
4.25”L Spacer
x 1
Small
Knurled Nut
x 1
Base
x 1
4.75”L Nipple
with Hex Nut
x 1
16” Dia.
7.5”
22.75”
7.25” Dia.
Lock Washer
x 1
Spring
Washer
x 1
Thumb Nut
x 1
Center
Column
x 1
Cord
Socket
Assembly
x 1
extruding from the bottom
of the Center Column and
secure with the Thumb
Nut. Hand tighten until
snug. Pull cord from Base
as you assemble parts
together to remove the
excess cord between
parts.
C. Thread the Hex Nut end of
the Nipple with Hex Nut
into the hex coupling on
the top center of the
Socket Assembly. By
using pliers, thread the
Hex Nut against the hex
coupling and hand tighten
until snug.
D. Place the Spacer and the
Check Ring over the top end of the
Nipple and secure with the Small
Knurled Nut. Hand tighten until snug.
E. Thread the Big Knurled Nut onto the top
end of the Nipple. Place the Flat
Washer and the Shade over the Nipple.
Adjust the Big Knurled Nut to proper
location for the Flat Washer, the Shade
and Finial. Secure by threading the
Finial onto the Nipple. Hand tighten
until snug.
F. Insert bulbs onto
sockets and screw
snugly into place.
Your fixture is now
assembled and
ready to use. Enjoy!
FINISH: VINTAGE BRONZE
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-800-645-3184
or visit us on-line at www.quoizel.com
PULL
PULL
PULL
PULLPULL
Product Specifications
| Brand: | Quoizel |
| Category: | Lamp |
| Model: | Tiffany TF3180TVB |
