PAEXARC1

For applications where ARC signals need to be extended above

HDMI cabling limitations to an amplier or distributed audio system.

Updated: May 2023

ARC DIGITAL

AUDIO EXTENDER

SAFETY INSTRUCTIONS

For optimum performance and safety, please read these instructions carefully before

use. Please keep this manual for future reference.

• To prevent electric shock, please ensure that all apparatus is properly grounded.

• Place the device in a well-ventilated area, do not block any ventilation openings.

• Do not expose this apparatus to rain or place it near water. Any liquid that goes

into the apparatus may cause a failure, re, or electric shock.

• Do not place the device on an uneven or unstable surface. The device may fall

resulting in a malfunction.

• Never insert anything metallic into the open parts of this apparatus. This may

cause a danger of electric shock.

• If a third-party power supply is used, please ensure that the power supply

specications meet the product requirements.

INTRODUCTION

The PulseAudio PAEXARC1 is an ARC Digital Audio Extender that allows digital audio to

be routed from a display, back to a remote location or amplier, over a single Cat5e/6

cable up to 492ft (150m). For displays without ARC capability, or when ARC settings are

not working as they should, the built-in “ARC Backup Plan” is featured where audio can

still be extended utilizing SPDIF. For applications where ARC signals need to be extended

above HDMI cabling limitations to an amplier or distributed audio system, the

PAEXARC1 is the perfect solution.

The range of the PAXEARC1 will vary depending on the HDMI/ARC sample rates.

For instance, higher sample rates, 192kHz, will be rated at 295ft (90m), while lower

sample rates, 96kHz, will be rated at 492ft (150m).

Product Features

• Extends ARC Digital Audio signals over Cat5e/6

• Supports a single HDMI ARC input and output

• Extends digital audio signals up to 492ft (150m) at 96kHz

or 295ft (90m) at 192kHz over a single Cat5e/6

• Built-in “ARC Backup Plan” with SPDIF input and output

• Supports Dolby / DTS 5.1CH and PCM 2CH audio formats

• CEC pass-through when HDMI®

ARC mode is enabled

• Dimensions: 3.5” x 2.8” x 0.8” (90mm x 72mm x 20mm)

• Weight: 6.2oz (175g)

Package Contents

(1) Digital audio extender set - TX and RX (2) USB-A to micro-USB cables

(2) 5V 2A USB power sdapters (1) Product manual

SPECIFICATIONS

Audio

Supported Audio Formats PCM 2CH, Dolby/DTS 5.1CH

Sample Rates

Optical / ARC (492ft / 150m)

32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz

ARC (295ft / 90m) 32kHz, 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

Connections

Transmitter

Input: (1) SPDIF, (1) ARC HDMI® In, (1) Micro-USB (Power)

Output: (1) CAT Out (Cat5e/6)

Receiver

Input: (1) CAT In (Cat5e/6), (1) Micro-USB (Power)

Output: (1) SPDIF Out, (1) ARC HDMI® Out

Technical & Mechanical

Housing Metal

Color Black

Dimensions 3.5” x 2.8” x 0.8” (90mm x 72mm x 20mm)

Weight 6.2oz / 175g

Power

Power Consumption

Transmitter: .35W

Receiver: .7W

ESD

Human-body Model: ±8kV (Air-gap discharge)

±4kV (Contact discharge)

Operating Environment

Temperature

Working: 0°C to 40°C / 32°F to 104°F

Storage: -20 to 60°C / -4°F to 140°F

Relative Humidity 20 to 90% RH (Non-condensing)

Product Specifications

Brand:	PulseAudio
Category:	Audio/video-converter
Model:	PAEXARC1
