Page 1/4
30" OSCILLATING
HIGH VELOCITY PEDESTAL FAN
MODEL 1PAFP30
OWNER’S MANUAL
2
RULES FOR SAFE OPERATION
READ AND SAVE THESE INSTRUCTIONS
CAUTION
Read and follow all instructions before
operating fan.
Do not use fan if any part is damaged or missing.
WARNING
• Toreducetheriskofreorelectricalshock,
do not expose to water or rain.
• Toreducetheriskofreorelectricalshock,
do not use this fan with any solid state speed
control device.
• Automatically operated device - To reduce
theriskofinjury,disconnectfrompower
supply before servicing.
• Ifthepowersupplycordisdamaged,
contact your local service center or a
qualiedelectriciantoinstallanappropriate
replacement cord to prevent any injury
or damage.
• The appliance does not apply to be used in
locationswherespecialconditionsprevail,
such as the presence of a corrosive or
explosiveatmosphere(dust,vapororgas).
• This appliance is not intended for use by
persons(includingchildren)withreduced
physical,sensoryormentalcapabilities,or
lackofexperienceandknowledge,unlessthey
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure
that they do not play with the appliance.
RULES FOR SAFE OPERATION:
1 Neverinsertngersoranyotherobjects
through the grill guard when fan is in operation.
2 Disconnect the fan from its power source
when moving from one location to another.
3 Disconnect the fan from its power source
when removing guards for cleaning.
4 Besurefanisonastable,atsurfacewhen
in operation.
5 Do not use fan in windows. Rain and moisture
may create electrical hazard.
6 Close supervision is necessary when this fan
isusednearchildren,theelderlyandpets.
7 Donotplacethefannearanopename,
cookingorheatingappliance,orhotsurface.
8 This fan should not be operated outside.
CAUTION Do not alter the fan’s assembly.
WARNING Be sure that both front and rear
guard screws are completely tightened in locking
position before operation.
RATING:
120V~60Hz,1.8A,220W
CLEANING
WARNING Unplug from electrical
supply source before cleaning.
1 Usesoftdampclothtoclean,
then wipe with dry cloth.
2 Do not use a cleaning solution
that is harmful to paints or plastics.
3 Do not bend the blades.
IMPORTANT: Surges in electrical power
or excessive heat may cause the fan to
turno.Waitapproximately15minutes
for the fan to resume operation.
Machine will need more frequent cleaning
if being used in an environment with high
particle pollution.
Plastic nails may be slightly larger than
holes in base, this is normal and ensures a
secure t. We recommend using a rubber
mallet to install the plastic nails.
WARNING Only use to grass or
ground of being similar to rugby court
and football eld, moreover must
instatll the plastic nails to make sure
the base is xed on the ground during
use to ensure the product stability.
3
1
2
3
4
5
Oscillation
Screw
Position
Screw
Clutch Plate
Flange
Bolts and
Washers
ASSEMBLY, OPERATING & CLEANING INSTRUCTIONS
ASSEMBLY INSTRUCTIONS:
1 Withascrewdriverandadjustable
wrench,attachtheoutertube
to the base using supplied
(5)screwsand(5)nuts.
2 Withtheadjustablewrench,
attachthemotorangeto
the outer tube plinth using
the pivot bolt.
WARNING: Fan motor
isextremelyheavy,we
highly recommend two
adults to assemble -
one adult to hold the
motor steady while one
adult tightens the pivot
bolt and the position screw.
3 Slide the rear guard onto the shaft
the of the motor and secure with the
pre-drilled bolts on the front of the
motor. Be sure the small hole for the
grill screw is positioned on the bottom
of the rear guard before securing it
to the motor.
4 Slidethefanbladeontotheshaft,
the set screw needs to be facing
inwardandtightenedontheat
indent of the shaft. Tighten the set
screw with included Allen wrench.
Please be vigilant that the fan blade
is secured correctly and tightly to
prevent safety hazards and
operational failure.
5 Connectthefrontguardandrearguard,fastentheclipsrunningalong
the boarder of the front guard to secure them together.
6 Install the grill screw to secure the front and back guards together.
4
