Page 1/40
Table of Contents
Main monitor stationDoor station
1. Introduction
2. Important Information
3. Preparation
4. Use on Smart Phone
5. Main Functions
6. Settings
7. Specifications
Video Intercom System
The images shown are for illustration purposes only and may not be an exact representation of the product.
Model Name Model No.
2
4
6
7
11
19
39
VL-SA74CX
VL-MA74CX
VL-VA504CX
Main Monitor Station (7 Inches)
Door Station
This system is an auxiliary system; it is not designed to provide complete protection from property loss. Panasonic
will not be held responsible in the event that property loss occurs while this system is in operation.
Customer care number: (+971) 48007262
Email:customercare@ae.panasonic.com
VL-VA504CXVL-MA74CXVL-SA74CX
Model composition
*1. Can be configured to be used as an extension monitor
*2. Product name used in this document
1.2.1 Supplied accessories
Caution:
β Before attempting to connect or operate this productοΌplease read the label on the rear of the main monitor.
Note:
β Accessories for installing the main monitor and the doorphone are described in the supplied Installation Guide
1.Introduction
1.1 Model Composition
1.2 Accessory Information
1.3 Features
7 TFT capacitive touch screenΚΊ
Hands-free intercom
2MP HD Video resolution
7 different melody ring tones for option
IP65 waterproof, damage-proof with IK08
Support releasing electric door lock
Support maximum 2 outdoor units works with 4 monitors, and 2 IP CCTV cameras
Video / Snapshot recording saved in Micro SD card
External storage up to 256GB
Multi-language option
Brightness, melody volume can be adjusted via monitor
White LED for color night vision
Work with Panasonic SmartWiFi App
Remote video intercom with your visitor via your mobile phone
Snapshot with built in memory of 100 images
1. Alternating current (A.C.) 2. Direct current (D.C.) 3. Protective earth 4. Protective bonding earth 5. Functional
earth 6. For indoor use only 7. Class P equipment (equipment in which protection against electric shock relies on
Double Insulation or Reinforced Insulation) 8."ON" (power) 9."OFF" (power) 10.Stand-by (power) 11."ON"/"OFF"
(power; push-push) 12. Caution, risk of electric shock
Graphical symbols for use on equipment and their descriptions
β In the event of problems, you should contact your equipment supplier in the first instance.
β The available products differ depending on your region. For more information, please consult your dealer
β In this document, the suffix of each model number (e.g., the"CX"in"VL-SA74CX") is omitted unless necessary.
When the suffixes are used to describe models (e.g., "CX models"), the suffixes refer to all models in the series
β Design and specifications are subject to change without notice
β The illustrations in the supplied document may vary slightly from the actual product.
1.Introduction
1.4 General Information
Product Specifications
| Brand: | Panasonic |
| Category: | Intercomsysteem |
| Model: | VL-SA74CX |
