ORNO OR-GM-9035 Manual
ORNO
Power outlet
OR-GM-9035
Read below 📖 the manual in Italian for ORNO OR-GM-9035 (5 pages) in the Power outlet category. This guide has been helpful for 2 people and has been rated 4.5 stars on average by 2 users
Page 1/5
Product data sheet
ORNO GROUP Sp. z o. o. All rights reserved. Page 1 / 5
Update date: 2024-07-17 10:21:05
Recessed furniture socket with flat milled edge, USB
charger and 1.5m cable, 2x2P+E, 2x USB (type A+C; 3.6A),
black
Marka: | Symbol: | Ean: Orno OR-GM-9035/B 5908254829116
PRODUCT DESCRIPTION
The recessed furniture socket with a flat, milled edge is characterised not only by its minimalist design, but
also by its functionality. The milled edge allows to install the socket cassette esthetically, so that mounting
hole and cut lines remain covered.
Product data sheet
ORNO GROUP Sp. z o. o. All rights reserved. Page 2 / 5
Update date: 2024-07-17 10:21:05
A distinguishing feature of the new powerbox model is the complete bottom housing, which facilitates
installation and improves safety. No access to the mains sockets and an additionally covered cable gland
with a rubber seal protects against unwanted ingress and mechanical damage. The socket also has safety
shutters, and the whole housing enables closing the hinged cover and hiding the unused device flat in the
countertop.
The black, powder-coated socket match well with the finish of most furniture and will colourfully blend in with
most arrangements. The refined shape makes the use of a furniture recessed socket a stylish alternative to
the usual extension cords or power strip, and effectively avoids tangled cables.
The use of high quality materials, zinc and steel alloys, guarantees safe and comfortable use for many years
and resistance to damage.
The device has an IP20 protection level and is ideal for use in the home, office, reception, conference room,
school study, dry zones of the kitchen or in a hotel.
The closing, recessed furniture socket allows connecting two devices at the same time, as it is equipped with
two earthed French-type sockets (2x2P+E) and another two, powered from two USB ports (type A and C).
The maximum load of the device is 3680W. You can easily plug in, for example, a home office in the form of a
monitor and laptop, charge a phone or powerbank, and close the socket when finished working. Equipped
with a 1.5m cable - ready to plug in and use.
TECHNICAL DATA
General information:
Model: Do wbudowania
Folding: tak
Extendable: nie
Nominal voltage [V]: AC 230
Frequency [Hz]: 50
Max. load [W]: 3680
Standard of the socket: francuski (typ E)
Number of socket outlets French standard (Type E): 2
Number of USB connections: 2
USB port type: 1xUSB-A, 1x USB-C
Product data sheet
ORNO GROUP Sp. z o. o. All rights reserved. Page 3 / 5
Update date: 2024-07-17 10:21:05
With built-in USB power supply: tak
Output voltage of the USB charger: 5V/3,6A
Degree of protection (IP): IP20
Shape: ProstokÄ…tny
Length: 132
Width: 265
Height: 67.5
Edge thickness: 2.5
Dimensions of the mounting hole -length: 112
Dimensions of the mounting hole - width: 226
Built-in depth: 65
Material: stop cynku i stal
Color: Czarny
Wire length: 1.5
Wire cross section: 1.5
Others: pełna dolna zabudowa
Product Specifications
| Brand: | ORNO |
| Category: | Power outlet |
| Model: | OR-GM-9035 |
