Page 1/21

u ’ Gser s uiDe

•IMPORTANT•

SAVE THIS BOOKLET!

CoMMerCial

Xl2100rHs

HIGH SPEED UPRIGHT VACUUM

CLEANER WITH

CLEANING SYSTEM

s i M p l Y a M a Z i n G ®

Includes:

• Safety Warnings

• Warranty

• Operating Instructions

• Trouble Diagnosis

• Accessories

E N G L I S H

USA: 1-888-768-2014

WWW.ORECKCOMMERCIAL.COM

When using an electrical appliance, basic

precautions should always be followed,

including the following:

READ ALL INSTRUCTIONS BEFORE

USING THIS VACUUM CLEANER

WARNING

To reduce the risk of fire,

electric shock, or injury:

• Do not leave appliance unattended when plugged in. Unplug

from outlet when not in use and before servicing.

• Do not use outdoors or on wet surfaces.

• Do not operate the unit while in the upright and locked position.

• Do not let the unit run while in any one stationary position for any

period of time. Keep the unit moving while in operation.

• Do not allow to be used as a toy. Close attention is necessary

when used by or near children.

• Use only as described in this manual. Use only manufacturer’s

recommended attachments.

• Do not use with damaged cord or plug. If appliance is not

working as it should, has been dropped, damaged, left outdoors,

or dropped into water, return it to a service center or call

customer service at

US: 1-888-768-2014

• Do not pull or carry by cord, use cord as a handle, close door on

cord, or pull cord around sharp edges or corners. Keep cord

away from heated surfaces.

• Do not run appliance over cord.

• Do not unplug by pulling on cord. To unplug, grasp the plug, not

the cord.

• Do not handle plug or appliance with wet hands.

• Do not put any object into openings. Do not use with any opening

blocked; keep free of dust, lint, hair and anything that may reduce

air flow.

• Keep hair, loose clothing, fingers and all parts of body away from

openings and moving parts.

• Do not use to pick up anything that is burning or smoking, such as

cigarettes, matches, or hot ashes.

• Do not use without filter bag assembly in place.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up flammable or combustible liquids, such as

gasoline or lighter fluid, or use in areas where they may be

present.

• Do not use appliance in an enclosed space where flammable,

explosive or toxic vapors are given off by oil base paint, paint

thinner, some mothproofing substances, or in an area where

flammable dust is present.

• Do not pick up toxic material such as chlorine bleach, drain

cleaner, gasoline, etc. with this appliance.

• Use caution when vacuuming over area rug edges and fringe.

•

Product contains chemicals known to the State of California

to cause cancer and birth defects or other reproductive

harm.

•

Keep cord away from heated surfaces.

%(&% %&$'&! %

;>;991>/5-8'?1

E N G L I S H

T Cable of ontents

BEFORE OPERATING

CLEANER, READ ALL

INSTRUCTIONS IN THIS

MANUAL CAREFULLY.

Maintenance and Customer Service,

Important Safety Instructions . . . . . . . . page 2

Warranty,

Troubleshooting Guide . . . . . . . . . . . page 3

Assembly,

Operating Instructions . . . . . . . . . . . . page 4

Operating Instructions cont.,

To Replace Paper Filter Dust Bag . . . page 5

How to Replace a Worn Belt,

Stuffing or Blockage . . . . . . . . . . . . . page 6

Using an Oreck Fresh Air Tab®,

Grounding Instructions,

To Adjust or Replace Brush . . . . . . . . page 7

>-:J-5?A501ZA@585?-@5;:

?<-P;8A5-18'?A->5;

Your ORECK vacuum cleaner is a product of precise engineering.

The motor bearings are permanently lubricated and should not be

oiled. If you require additional information or have problems with

your ORECK appliance, you may call ORECK commercial customer

service at: '% 1-888-768-2014

Please specify the model number and serial/code number which

can be found on the data plate on the back of the vacuum.

Save your sales or purchase slip. Should your ORECK appliance

require warranty service in the U.S.A., present this slip to the

Authorized Service Center as your proof of purchase date or, in

Canada, call customer service.

Maintenance and

C Sustomer ervice

Accessories

Sold Separately

& "$&

1. Dust Bag, Pack, Regular PK800025

2. Belts, 3 Pack 0300604

3. Oreck Fresh Air®Tabs AIRTABS

IMPORTANT

SAfETY INSTRUCTIONS

E N G L I S H

Warranty

SAVE SERVICE CALLS...CHECK THESE FIRST:

• Is the disposable filter dust bag full?

• Are pores of filter dust bag clogged with powder or fine dust?

• Is anything clogging the revolving brush, lower tube, intake

opening, fan housing or connector assembly opening?

• Is the belt in place and turning the brush?

• Are the brush ends in the proper location?

• Does the brush turn freely? Are hair, string or rug fibers wound

around the brush?

T Groubleshooting uide

Cleaner

will not run

Cleaner

Does not piCK up

Not plugged in

properly.

No electricity in

wall outlet.

Filter bag is full.

Nozzle or intake

pivot clogged.

Belt is broken or

stretched.

Brush is worn.

Bag tube clogged.

Bag pores are

clogged with fine

dust.

Impeller fan is

broken.

Revolving brush is

not even at both

ends.

Be sure cleaner is

firmly plugged

into wall outlet.

Check electrical

source–fuse or

circuit breaker.

Replace filter bag.

See “To Install

Paper Filter Dust

Bag.”

Clear obstruction.

Replace belt.

See “ To Adjust or

Replace Brush.”

Clear obstruction.

Change bag.

Return to Service

Center for repair.

Check brush roll

end cards. Make

sure words “old”

or “new” match at

each end.

proBleM ossiBle ourCe reas to HeCKp s a C

Whenever calling, please be sure to have your model and

serial number from data plate.

CALL COMMERCIAL CUSTOMER SERVICE HOT LINE

US: 1-888-768-2014

all otHer serViCinG sHoulD Be Done BY an

oreCK autHoriZeD serViCe Center.

WARNING: Unplug cord from

electrical outlet before servicing.

Product Specifications

Brand:	Oreck
Category:	Vacuum cleaner
Model:	XL2100RHS
