OVERALL DIMENSIONS
Product Specification Revised 7/16
ZEP30SKSSMONOgRAM 30" PIZZA OVEN
Dimensions in parentheses are in centimeters unless otherwise noted.
Actual product dimensions may vary due to manufacturing tolerances.
SPECIFICATIONS
Overall Width 29 3/4" (75.6 cm)
Overall Height 19 3/4" (50.2 cm)
Overall Depth 29 3/8" (74.6 cm)
Overall Oven
Interior Capacity 1.45 cu. ft.
Oven Interior
Dimensions (W x D)
19.38" x 17.88 "
(49.2 x 45.4 cm)
Minimum Cabinet Width 30" (76.2 cm)
Minimum Cabinet Depth 24" (61.0 cm)
Minimum Base Support 200 lbs. (90 kg)
Cutout Width 28 1/2" (72.4 cm) Min
28 5/8" (72.7 cm) Max
Cutout Height 18 1/4" (46.4 cm) Min
18 5/16" (46.5 cm) Max
Cutout Depth 24" (61.0 cm) Min
Volts/Hertz/Amps 240/208 V AC, 60 Hz, 50A
Conduit Length 43"
Electrical Rating 10.4 kW at 208V
12.0 kW at 240V
Shipping Weight 275 lbs. (124.7 kg)
ATTENTION ELECTRICIAN:
A 240/208V, 60Hz, 50 Amp circuit is
required. An individual properly grounded
branch circuit or circuit breaker is required.
Hardware junction box is required for
built-in product.
FRONT VIEW
29 3/4"(75.6)
19 3/4"
(50.2)
SIDE VIEW
29 3/8"(74.6)
23 7/8"(60.6)
19 3/4"
(50.2) 18"
(45.7)
5 1/2"
(13.9)
TOP VIEW
28 1/4"(71.8)
23 7/8"
(60.6)
29 3/8"
(74.6)
5 1/2"
(13.9)
NOTES
Product Specification Revised 7/16
ZEP30SKSSMONOGRAM 30" PIZZA OVEN
47"
(119.4) min
28 1/2" (72.4) min
28 5/8" (72.7) max
24" (60.9) min
cutout depth
18 1/4" (46.4) min
18 5/16" (46.5) max 4" (10.2) min
to bottom of
junction box
INSTALLATION
FRONT VIEW
INSTALLATION
SIDE VIEW
ELEC
Solid enclosure required
on the top, bottom, left and
right sides and back of oven
WALL INSTALLATION
A 47" is the required
minimum installation
height. Oven may be
installed higher based
on owner preference.
B Back of standard-
depth cabinet may
need to be removed
to install oven at
correct depth.
Drywall is acceptable
as back enclosure.
C Platform must be
able to support 200
lbs (90 kg)
D Solid enclosure
required on the top,
bottom, left and right
sides and back of
oven
E Junction box location
(May also be located
in adjacent cabinet)
For more details, refer to the installation instructions for this product on Monogram.com.
Dimensions in parentheses are in centimeters unless otherwise noted.
C
E
B
A
D
FEATURES AND BENEFITS
Product Specification Revised 7/16
ZEP30SKSSMONOGRAM 30" PIZZA OVEN
HANDCRAFTED LUXURY
Can be found in every aspect of the design,
from the polished stainless exterior to the
simple touch controls
PIZZERIA-QUALITY PERFORMANCE
Is designed to match the capabilities of the best
restaurant pizza ovens to help home chefs achieve
the perfect slice
ELECTRIC HEATING ZONES
Combine the crisping performance of traditional
coal- and wood-burning pizza ovens with the
precision and ease of a sophisticated appliance
CAPACITIVE TOUCH LCD CONTROLS
Allow for easy selection of preset cooking options,
including a variety of pizza settings and choices for
roasting vegetables
BUILT-IN INSTALLATION
Is made possible with a standard 30"-width
cabinet cutout
INTEGRATED OVEN VENTILATION SYSTEM
Allows for simple installation, with no additional
ductwork required
