Milab DC-96C
Quick Guide Manual
Thank You for Choosing a Milab Microphone!
With a history that goes back to the 1930s, Milab is one of the oldest,
continuously operating microphone manufacturers in the world.
Every one of our microphones is handcrafted in our plant in southern Sweden.
Our quality control is meticulous and all microphones have to pass several
stages of testing, including rigorous audio tests in our anechoic chamber.
We believe in our products, which is why every microphone is delivered with
its own individual frequency chart and our industry-leading lifetime warranty.
Congratulations on your purchase and welcome to the Milab family!
Thomas Nöjdh, President
Package Includes
Milab DC-96C condenser microphone
Milab 3127 stand holder
Milab 3403 windscreen
Individual frequency chart
Quick guide manual
The Milab DC-96C Condenser Microphone
The DC-96C is the newest addition to the classic Milab DC family. It is a
side-addressed, large membrane microphone built around the Milab 2900
rectangular capsule and has been designed mainly for studio work, but is also
an excellent choice for many live/stage applications.
The original DC-96 was released in the late 1960s. After an update, it was
replaced by the DC-96B in 1983 which would become one of the most iconic
Milab models.
The DC-96C is suitable for a wide range of applications, including studio
vocals, acoustic guitar and piano, hi-hats and overheads, guitar amps and
more.
Connection
The DC-96C can be connected to any mic input, mixer/amplifi er, or mic
preamp using a standard microphone cable (XLR). The microphone is
designed for phantom powering at 48 V (P48, IEC 1938) with positive
voltage on the audio lines versus the cable shield.
Microphone XLR pinout:
1: Ground (shield)
2: Hot (+ phase)
3: Cold (- phase)
If the input device does not support phantom power, an external power supply
has to be connected between the microphone and the input. Make sure that the
extra phantom power has a DC-free output against the mixer, otherwise an RC
network has to be incorporated to block the 48 VDC.
Connecting the microphone to an unbalanced input:
Connecting the microphone to an unbalanced input without a transformer.
Pin 2 is the “hot phase“ and should be connected to the input. Pin 3 should
be left open:
