Metra. The World’s Best Kits.®MetraOnline.com © COPYRIGHT 202 METRA ELECTRONICS CORPORATION 4

I N S TA L L AT I O N I N S T R U C T I O N S

J -101P 8

Attention! Let the vehicle sit with the key

out of the ignition for a few minutes before

removing the factory r adio. When testing the

aftermarket equipment, ensure that all factory

equipment is connected before cycling the

key to ignition.

• Driver and passenger specific lower dash grilles

•Cut templates and hardware

•ABS injection molded, silver painted surround

•Metal stamped grille insert

•Used with OE or JP-1014 speaker upgrade dash pods

•1 year warranty from defects

KIT COMPONENTS

• A) • B) Template (Left & Right) Cut-in grilles (Left & Right) • C) Backing plates (Left & Right)

TOOLS REQUIRED

• Panel removal tool

• Phillips screwdriver

•7mm and 13mm socket

TABLE OF CONTENTS

Left dash Disassembly ...................................... 2-3

Dash cut-in...................................................................4-5

Passenger side Disassembly....................... ...... 6-7

Jeep Wrangler (JL) 2018-2023,

Jeep Gladiator 2020-2 302

Visit for more detailed information about the product and up-to-date MetraOnline.com

vehicle specific applications

KIT FEATURES

ACB

REV. 1/17/2024 1

Dash cut-in...................................................... .................8

386.257.1187

MetraOnline.com

DASH DISASSEMBLY

1. Unclip and remove the panel below the

steering column. Remove (2) Phillips

screw exposed. (Figures A,B)

2. Unclip, unplug, and remove the climate

control panel. (Figure C)

(Figure D)

(Figure E)

3. Remove (2) Phillips screws securing

the radio trim panel, then unclip and

remove. (Figure D)

4. Remove (1) Phillips screw securing the

dash pad, then unclip and remove.

(Figure E)

(Figure A)

(Figure B)

(Figure C)

REV. INSTJP-10181/17/2024 3

DASH DISASSEMBLY

5.Remove (8) Phillips screws securing the

instrument panel on the left side, and

airbag panel on the right side.

(Figure F, G)

6.Unclip the steering column shroud then

set aside. (Figure H)

Driver’s side removal:

7.Open the driver’s door, then unclip and

remove the panel on the side of the

dash. Remove (5) Phillips screws

exposed. (Figure I)

8.Remove (5) Phillips screws securing

the speaker panel, then unclip and

remove. (Figure J)

(Figure I)

(Figure F)

(Figure G)

(Figure H) (Figure J)

Tip

TipTip:

: : Now would be an excellent time to install

a pair of JP-1014 6.5" speaker pods. For more

information scan the QR code below.
