INSTALLATION INSTRUCTIONS FOR PART 99-8223
APPLICATIONS
Toyota Corolla
2009-10
KIT FEATURES
• DIN Radio With Pocket Provision
• ISO Mount Radio with Pocket Provision
• Painted To Match Factory Dash
99-8223= BLACK
99-8223S= SILVER
• A) Radio Housing • B) Radio Housing Trim Plate • C) Radio Housing Brackets
•D) ISO Brackets • E) ISO Trim Plate
KIT COMPONENTS
TOOLS REQUIRED:
Small Flat Blade Screwdriver/ Panel Removal Tool
• Phillips Screwdriver
1-800-221-0932
© COPYRIGHT 2010 METRA ELECTRONICS CORPORATION
www.metraonline.com
ABC
99-8223/
99-8223S
DE
Harness & Antenna Connections (sold separately)
• 70-1761 Toyota Harness 87-up
• TYTO-01 Toyota Amp Interface 03-up
Dash Disassembly
-
Toyota Corolla 2009-10 . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . 1
Kit Assembly
- DIN Radio with Pocket Provision . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
- ISO Mount Radio with Pocket Provision . . . . . . . . . . . . . . . . . . . . . . . . 3
Final Assembly . 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TABLE OF CONTENTS
99-8223
*Note:
Refer also to the instructions included with the aftermarket radio.
K
NOWLEDGE IS
P
OWER
Enhanc our installation and fabrication skille y s by
enrolling in the most recognize an espected d r d
mobile electronics sch ol in our industro y.
Log onto www.installerinstitute.co cam or ll
800-354-6782 for more informatio an take stepn d s
towa a etter tomorrord b w.
99-8223 DASH DISASSEMBLY
Toyota Corolla 2009-10
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the (4) side trim
panels from the right and left side of
the radio and a/c controls. (
Figure A)
2
Unclip and remove the a/c vent panel
above the factory radio.
(Figure B)
3
Remove (4) 10 MM bolts securing the
radio.
(Figure C)
4
Remove (4) plastic clips from the
back of the factory radio. (Retain the
clips for re-use during kit assembly.)
5
Continue to kit assembly.
