Page 1/12
Page 1 of 12
Assembly Instructions
Model: Jeep JL (Wrangler) & JT (Gladiator)
Description: MB Quart Jeep JL Wrangler and JT Gladiator 8” Soundbar
Disclaimer: Currently not compatible with Jeep Sky One-Touch Power Roof
Part Number: MBQJ-48HRGB - Horn w/ RGB Enclosure
MBQJ-48CRGB - Coaxial w/ RGB Enclosure
MBQJ-48H - Horn Enclosure
MBQJ-48C - Coaxial Enclosure
MBQJ-48E - Unloaded Enclosure
Assembly Time: 120 Minutes (2-Hours)
No. Component Name Qty
1 Soundbar 1
2 Transparent Grill (MBQJ-48HRGB & MBQJ-48CRGB Only) 4
3 Silver Grill (MBQJ-48H, MBQJ-48C Only) 4
4 Black Grill 4
5 ST4.2 x 50mm Screws (Unloaded) 16
6 MB Quart Speaker Logo Badge (Excluding Unloaded) 4
7 MB Quart Sticker 2
1 Bojo or Panel Tool
2 Long Flat Head Screwdriver
3 10mm Socket & Rachet
4 T25 Torx Driver
Parts List
Tools Required
Before you begin, read through these instructions and check that all parts are
present. Please note that MB Quart cannot assume any responsibility for damage
resulting from incorrect installation.
Page 2 of 12
Disassembly Instructions
● Disconnect negative battery
terminal.
● Remove driver and passenger
front roof panels per the vehicles
owner manual.
● Remove four T25 Torx from the
passenger side front ROPs (Rollover
Protection System) and then carefully
unclip and remove from vehicle and
set aside (Repeat on driver side).
Page 3 of 12
Disassembly Instructions
● Remove three or four T25 Torx from
the passenger side rear lower ROPs.
● Remove two T25 Torx from the
passenger inside rear ROPs. Then
carefully unclip and remove from the
vehicle. Repeat the previous two steps
on the driver side.
● Remove three T25 Torx from the front
of the middle ROPs cover.
