Operator’s Guide and
Installation Instructions
GMR-1.5
Bluetooth® Source Unit
Congratulations for choosing the GMR-1.5 Bluetooth®
Source Unit by MB Quart. For more detailed information
about the product, please visit MBQuart.com
CAUTION
Always consider consulting a professional audio installation
technician before installing any mobile audio components. Be
careful and take your time. Do not let wires make contact with
metal edges, sources of moisture or hot engine components.
General Information
Marine & Powersports Source Unit
160 Watts Peak Power
Pre Ampliîšżer Unbalanced Line Outputs
Gauge Mount
MB Quart Bluetooth Connect
Bluetooth Connection
USB Input
Auxiliary RCA Input
Installation & Power Speciîšżcations
4 Channels x 40 Watts (160 Watts Peak Power)
2.99” / 75.95mm Total Mounting Depth
3.14” / 79.76mm Cut Out Diameter
Audio & Other Section
Power Output: 4 x 40 Watts Maxx
Power: DC +12 Volt Battery
Stereo Separation: -65.5dB @ 5kHz
Load Impedance: 4 - 8 Ohms / Channel
USB Connector
(AUX)
Red - RCA Input (R)
White - RCA Input (L)
Green - SUB Output (Mono)
Red - Accesory
Yellow - +12 Volts
White/Black - Front Left (-)
Blue - Remote Output
Black - Ground (-)
Purple/Black - Rear Right (-)
Purple - Rear Right (+)
Green/Black - Rear Left (-)
Green - Rear Left (+)
Gray/Black - Front Right (-)
Gray - Front Right (+)
White - Front Left (+)
Wiring and Connections
