F80P & F130P FLEX-SELECT® Series
Adaptable Broadcast Spreader
Assembly and Operating Instructions
Remove all parts, hardware, and assemblies from carton
and lay them out on the oor to help in assembly.
Below are tools needed for assembly - 7/16”
wrench, ratchet and 7/16” socket, and pliers.
The following photos are for assembly
purposes, and please follow them from left to
right, top to bottom.
PAGE 14-2015 Pt# F52153
WARNING
Do not use air tools to assemble.
To prevent seizing coat all bolts
with a wax or grease prior to
installation.
PLEASE CONTACT US: IF YOU ARE MISSING ANY PARTS, HAVE ANY DIFFICULTY IN ASSEMBLY, OR HAVE ANY
QUESTIONS REGARDING THE SAFE OPERATION OF THIS SPREADER. THIS MODEL INCLUDES LIFETIME
TECHNICAL SUPPORT. SUPPORT HOT LINE: 800-294-0671
HELPFUL HINTS:
;If your spreader does not spread evenly, be sure the FRONT on the gear box points to the front of the spreader. The
impeller must turn clockwise. Reversing the gearbox will cause the impeller to turn counter clockwise. Clean the impeller
after each use as some fertilizer may become stuck on the impeller blades and will cause uneven spreading.
;Your spreader is designed to be pushed at three miles per hour, which is a brisk walking speed. Slower or faster speeds
will change the spread patterns. Wet fertilizer will also change the spread pattern and ow rate.
;Clean and dry your spreader thoroughly after each use, wash between the shut-off plate and bottom of the hopper
regularly. To prevent rust, coat all metal parts (inside and out) including the frame tubes with a light oil, silicon spray, or
Fluid Film®.
;Gears are permanently lubricated at the factory. Do not open the gearbox or dirt may enter.
;When using to prevent damage to the gearbox remove salt from the hopper daily. Rock Salt Rock Salt will reconstitute
back into a solid block if left in the hopper overnight and will damage your gearbox if pushed with the salt in place.
PAGE 2
ASSEMBLY
1
2
3
4
PAGE 3
ASSEMBLY - continued
5
6
7
8
